4.6 MULTI-BARCODE EDITOR

The Multi-Barcode Editor allows deciding the output sequence of a concatenation of
barcodes. Up to five barcodes can be specified. When enable this mode, it will force the
scanner to apply Laser mode as the scan mode. For 1504 to concatenate barcodes, the
maximum output data length of all the barcodes is 10 KB after configuration. When the
data length exceeds 10 KB, the concatenation will not take effect.
Note: The Multi-Barcode Editor has nothing to do with
The barcodes that are found meeting the specified criteria below will be arranged in the
desired sequence.
Code Type
4-digit barcode length, excluding prefix, suffix, length code, etc.
Matching the first character of barcode data
144
User Guide
Multi-Barcode Mode.
Enter Setup
