4.2.1 SELECT A SET FOR CHARACTER SUBSTITUION

1) Read the barcode above to enable character substitution by set.
For example, have the scanner read the "Set 1" barcode to configure the first set of
character substitution. The scanner will respond with one short beep, high tone, to
indicate more setup barcodes are required.
2) Read the "Hexadecimal
substitution. For example,
KEY TYPE = NORMAL
Read "3", "0", "2", and "D" to replace the character "0" with a dash "-".
Read "3", "0", "2", "D", "3", and "0" to replace the character "0" with a dash "-0".
KEY TYPE = SCAN CODE
Replace the character "0" with "a" (= "1C" on the scan code table):
1. Read "3" and "0".
2. Read the "Scan Code" barcode.
3. Read "1" and "C".
KEY TYPE = NORMAL + KEY STATUS = SHIFT
Replace the character "0" with "!" (= "Shift" + "1" on keyboard):
1. Read "3" and "0".
2. Read the "Add Shift" barcode.
3. Read "3" and "1".
3) Read the "Validate" barcode to complete this setting. (The defined set or sets will be
applied to all symbologies by default.)
Value" barcode on page 194 for the desired character
Chapter 4
Configure Set 1
Configure Set 2
Configure Set 3
Update
Defining Output Format
117
