5.2 CHARACTER SUBSTITUTION

Character substitution is performed on every occurrence of the first character specified. If
only one character is specified, every occurrence of that character in the barcode will be
taken away.
The first character will be replaced by the second character(s).
Up to three sets of character substitution can be configured.
Note: The character substitution is performed only on the barcode itself and before the
processing of editing formats. It is not applicable to the Prefix/Suffix Code, Code
ID, Length Code, or any Additional Field.

5.2.1 SELECT A SET FOR CHARACTER SUBSTITUION

Configure Set 1
Configure Set 3
1) Read the label above to enable character substitution by set.
For example, have the scanner read the "Set 1" label to configure the first set of
character substitution. The scanner will respond with one short beep, high tone, to
indicate more setup labels are required.
2) Read the "Hexadecimal
For example, have the scanner read (1) "3", "0", "2" and "D" to replace the character
[0] with a dash [-] for Set 1, and (2) "3", "0", "2", "D", "3" and "0"to replace the
character [0] with a dash [- 0] for Set 2.
3) Read the "Validate" label to complete this setting. (The defined set or sets will be
applied to all symbologies by default.)
94
User Guide
Value" label on page 142 for the desired character string.
Configure Set 2
Enter Setup
