Table 5 shows the International and PC Line Character sets from 32 through 255.
Table 5: International and PC Line Draw Character Set

3.7.4 Printer Graphic Commands

Command String
ESC - 'a' – n
ESC - 'J' – n
ESC - 'P' - '#'
ESC - 'P' - '$'
ESC - 'V' - n1 – n2
ESC - 'v' - n1 – n2
3.7.5 Magnetic Card Reader Commands (When MCR is installed)
Command String
ESC - 'M' - 'nnm' - CR
ESC – 'C'
1500T User's Guide
Printer Action
Select dot line spacing between printed lines.
Graphic Line Feed command
Select Online mode, characters printed as received.
Select Buffer mode, characters are printed on (^ D)
8-bit Graphic command
RLE Compressed Graphic command
Printer Action
Select MCR with (nn) auto timeout
Where nn="00" to "99"
m=1: Reads track 1 only
m=2: Reads track 2 only
m=3: Reads track 3 only
m=4: Reads track 1 & 2
m=5: Reads track 2 & 3
m=6: Reads track 1, 2 & 3
Cancel MCR read process
Rev 2.1 20
