3.6 Magnetic Stripe Reader (Option)

The Magnetic Card Reader is a factory-installed option. This option requires special
application software to read and process cards with a magnetic stripe, such as credit
cards or driver's license
Note: Refer to the
Quickly swipe the card through the reader either left to right or right to left. The
magnetic stripe must be facing toward the paper supply door as indicated below while
it is passed through the reader
Refer to Table 4 for the description of the Magnetic Card LED Status.
LED indicator
Green
Red
1500T User's Guide
Figure 1 for location of the optional magnetic stripe reader
FIGURE 9: MAGNETIC CARD SWIPE
Table 4 - Magnetic Card LED Status
State
ON Ready/waiting for card to be swiped.
OFF Good swipe - Card data read
Card not ready to be swiped.
ON Error reading card's data.
