- Page 1 Revision: 1.0 8/3/2009 APEX 4 User’s Guide Rev 1.0...
-
Page 2: Table Of Contents
4.6 Trouble Shooting....................23 4.7 Printer Supplies.....................24 5. Specifications ....................25 5.1 Printer Specifications (subject to change without notice) ..........25 5.2 Supply Specifications .....................26 5.3 Regulatory Notes....................27 6. Customer Support..................28 6.1 Online Technical Assistance..................28 6.2 Technical Support Request..................28 APEX 4 User’s Guide Rev 1.0... -
Page 3: Declaration Of Conformity
285 Bear Hill Road, Waltham, MA 02451, USA Telephone: +1 781 890 7440 Declares that the Product Product Name: Portable Receipt Printer Model Number: APEX 4 Optionally Containing: 1) Bluetooth™ radio short range OEM module from connectBlue ab, cB-0701-01; FCC ID PVH 070101.Conforms to R&TTE Directives:... -
Page 4: General Precautions
In this manual and on the Printer and Accessories we make use of internationally recognized safety symbols as follows: Caution! Refer to the explanation in this Manual Caution! Risk of electric shock Double Insulation or Reinforced Insulation DC, Direct Current or Voltage AC+DC, Current or Voltage APEX 4 User’s Guide Rev 1.0... -
Page 5: Getting Started
1. Getting Started 1.1 Unpacking the Printer The APEX 4 portable printer is a full featured portable receipt printer designed for varied job environments including field service, field sales, hospitality and restaurants, ticketing and many others where point of service receipts are required. The package contains: ... -
Page 6: Installing And Charging The Battery Cartridge
Note: If paper door does not open easily, tap the printer against the palm of your hand near the paper door hinge. Note: Ensure that battery side with 2 contact terminals is facing down to make contact with the spring probes inside the battery compartment APEX 4 User’s Guide Rev 1.0... - Page 7 Note: The wall mounted charger is a Class II equipment. Multiple plug configurations comply with most international standards. The wall mounted charger is not supplied with plugs for use in Korea. Model APEX 4 Input Voltage/Current 100-240 VAC/ 0.4A Input Frequency 47-63 HZ APEX 4 User’s Guide Rev 1.0...
-
Page 8: Reading The Led Status
Do not use a charger not approved by Extech for use with the APEX 4. Use of an unapproved charger could damage the battery pack or the printer and will void the warranty. The battery terminals are well recessed inside the printer. Do not allow them to contact conductive material since this may create a short circuit which could cause injury or start a fire. - Page 9 GREEN mode. (USB cable is plugged in and Dip Switches 5 Reader and 7 are ON) & Flashing Printer Error Note: If USB is unplugged, LED will flash Amber until printer is reset manually APEX 4 User’s Guide Rev 1.0...
- Page 10 Allow print head to cool off: Print head is hot. Printer restart print temperature will stop printing Flash Fast recommended is 75 Firmware upload via Blue Cycle printer power to serial cable is completed continue Flashing successfully APEX 4 User’s Guide Rev 1.0...
-
Page 11: Attaching Belt Loop System
To release the printer, press in on the two latches on the connector and pull the knob clear of the slot. Note: Do not force or pull the printer from the connector without pressing in on the two latches Shoulder Strap Latches Connection Knob FIGURE 5: KNOB CONNECTION AND QUICK CLIP APEX 4 User’s Guide Rev 1.0... -
Page 12: Loading Supplies
Place the paper supply roll into the paper supply well. Make sure the paper supply unwinds from the bottom as shown in Figure FIGURE 7: INSTALLING PAPER Note: Pull paper Roll Leader Out of Printer. Note direction of paper travel. APEX 4 User’s Guide Rev 1.0... -
Page 13: Tearing Paper
Note: Using the tear bar is the only way to tear the paper. Note: Pulling up and pulling sideways without using the tear bar can cause a paper jam due to paper misalignment in the print head mechanism APEX 4 User’s Guide Rev 1.0... -
Page 14: Using The Printer
Figure 9 shows a printing sample. 3.2 Connecting the Printer • The APEX 4 printer supports USB and Bluetooth ™ communication as default communication interfaces. WiFi communication and IrDA is also available as an optional feature. • USB, Bluetooth™, and 802.11 communication settings can be changed via a DIP switch located on the control card. -
Page 15: Setting Dip Switches
FIGURE 11: DIP SWITCH #2 SHOWN IN “ON” POSITION Note: Be careful when changing dip switch settings. Carefully use a pointer on the dip switch you are going to change. DO NOT use a screw driver or apply excessive force. APEX 4 User’s Guide Rev 1.0... -
Page 16: Dip Switch Functions
X stands for Don’t Care: Dip Switch 7 will override 1 and 2 Firmware Applies to Apex 4 - Version 1.10 or later, Check availability for other printer models Baud Rate and Parity are applicable to RS232 and IrDA communication mode ONLY Note: In order for changes to the dip switch configuration to take effect, the printer power must be reset. -
Page 17: Communications
3.4 USB Communication The APEX 4 printer comes equipped with a USB 2.0 slave port. Everything that can be done through the RS-232 port can now be done through the USB port. You may print to or send commands to the printer from a PC or any equipment that can act as a USB master. -
Page 18: Bluetooth Communications
Note: It is necessary for the mobile computing device you are using to discover and pairing the printer to establish Bluetooth communication. Note: Systems Integrators: Refer to the Bluetooth manual provided with your mobile computer and the Bluetooth section of the APEX 4 Developer’s Manual 3.6 802.11 Communications (Option) •... -
Page 19: Magnetic Stripe Reader (Option)
State Status indicator Green Ready/waiting for card to be swiped Card not ready to be swiped or Good swipe – Card data read Error reading card’s data FIGURE 12: USING THE MAGNETIC CARD READER APEX 4 User’s Guide Rev 1.0... -
Page 20: Printer Maintenance
We recommend using the cleaning pen, part number 757150, which is included with the printer. To order more cleaning pens, please contact your distributor or Extech Instruments. Do not use sharp objects to clean the print head. This may damage the printer and require service •... -
Page 21: Verifying Battery Charge State
4.2.1 Important Notes on Charging Batteries • The model APEX 4 printers require an adaptor output of 10VDC/1.32A. • The battery Fast-Charge is initiated each time the power adapter is connected to the printer • The fast-charge controller checks the battery’s voltage and temperature before the start of the fast recharge process. -
Page 22: Battery And Safety Information
The battery may explode 4.5 Recycling Batteries The Rechargeable Battery Recycling Corporation (RBRC) is a non-profit organization created to promote recycling of rechargeable batteries. For more information about how to recycle batteries in your area, visit http://www.rbrc.org APEX 4 User’s Guide Rev 1.0... -
Page 23: Trouble Shooting
Other than routine cleaning and other maintenance described in Section the printer is not intended to be serviced by the user. It must be returned to an Authorized Service Center. Under no circumstances should the user attempt to take the printer apart APEX 4 User’s Guide Rev 1.0... -
Page 24: Printer Supplies
4.7 Printer Supplies Part Number Description 78928U1-3 Apex 4 with USB, Class 2 Bluetooth® 78928U1R-3 Apex 4 with USB, MCR, Class 2 Bluetooth® Apex 4 with USB, 802.11b/g 78928U1-2 78928U1R-2 Apex 4 with USB, MCR, 802.11b/g 157261 Multi-Plug Battery Charger Adapter (US, UK, Euro &... -
Page 25: Specifications
Bold Font and Proportional Font Supported Bar Codes Codabar, Code 39, UCC/EAN – 128, UPC/EAN/JAN, Interleaved 2 of 5, Code 128, PDF 417 Memory Flash: 4MB SRAM: 2MB Charging Time Approximately 180 minutes Communications USB, Bluetooth, 802.11b APEX 4 User’s Guide Rev 1.0... -
Page 26: Supply Specifications
Black mark (on face of supply) Paper Roll Diameter Outside: 2.0 inches (51 mm), Inside: 0.40 inches (10 mm) Approved Vendors Kansaki: P300, P310, P350, P354, P390, P394, P530UV, TO281CA, OP200, TO381N Jujo: TF-50KS-E2C Honshu: FH65BV-3 APEX 4 User’s Guide Rev 1.0... -
Page 27: Regulatory Notes
Extech), it will be repaired (estimates are provided first if the repair cost is estimated above $100.00) and returned via UPS ground. The customer may elect a faster mode of transport at their cost. APEX 4 User’s Guide Rev 1.0... -
Page 28: Customer Support
Troubleshooting Guide. http://www.extech.com/printer/techSupport/troubleShootGuide.html 6.2 Technical Support Request If you need technical assistance regarding software, hardware or operation of Extech printers, please contact us at: Tech Support Form http://www.extech.com/printer/techSupport/support.html Email printertechsupport@extech.com Telephone +1-(781)-890-7440 +1-(781)-890-7864 APEX 4 User’s Guide Rev 1.0... - Page 29 Portable Printer Division http://www.extech.com/Printer Copyright © 2009 Extech Instruments Corporation. All rights reserved including the right of reproduction in whole or in part in any form.
