3.7.2 Printer Font Commands – Courier Character Set:
Font Name
24 CPI normal
21 CPI normal
19 CPI normal
16 CPI normal
12 CPI normal
13 CPI rotated
MSP Font 10-32 CPI

3.7.3 Printer Font Commands

Command String
ESC - 'F' – 1
ESC - 'F' – 2
ESC - 'U' - '1'
ESC - 'U' - '0'

3.7.4 Printer Graphic Commands:

Printer Command String
ESC - 'a' – n
ESC - 'J' – n
ESC - 'P' - '#'
ESC - 'P' - '$'
ESC - 'V' - n1 – n2
3.7.5 Magnetic Card Reader Control Commands:
Command String
ESC - 'M' - 'nnm' - Cr
ESC – 'C'
3.7.6 Graphic Logo and Bar code commands:
Command String
ESC – L – G –n
ESC – G - 0x0FF
ESC – L – g – n
ESC - 'z' - n1 – n2 - L - [data]
ESC - 'Z' - n1 – n2 - L - [data]
ESC - 'Q' - 'J' – n
ESC - 'Q' - 'Q' – n
ESC - 'Q' - 'F' – m
ESC - 'Q' - 'B' – m
Character size (W x H)
8x23
9x23
10x23
12x23
16x23
14x16
Dot Matrix Fonts
:
Printer Action
Selects International character set
Selects PC Line Draw character set
Enable emphasized print.
Disable emphasized print.
Printer Action
Select dot line spacing between printed lines.
Graphic Line Feed command
Select Online mode, characters printed as
received.
Select Buffer mode, characters are printed on
(^ D)
8-bit Graphic command
Printer Action
Select MCR with (nn) auto timeout
Cancel MCR read process
Printer Action
Prepare printer to load image:
Loading Logo Complete:
Print stored logo image:
Print Bar Code without visible tex
Print Bar Code with visible text
Set Out of Paper Sensitivity
Set Forward Black Mark Seek
Reverse Black Mark Seek
Command String
ESC+'k'+'5'
ESC+'k'+'4'
ESC+'k'+'3'
ESC+'k'+'2'
ESC+'k'+'1'
ESC+'k'+'0'
ESC+'F'+'2' through '8'
Reverse Dot Feed
