Turn on the printer by pressing Power button and test the paper advance function by
pressing the Paper Feed Button. Verify that paper advances correctly.
Note: Paper Supply Roll
To prevent any possible damage to the print mechanism, it is important to verify that the
paper has not been fastened to the inside core in any way. The paper should be wound on
the core in such a way that the end of the paper will unwind freely from the core. If fastened
by tape or glue, the core will be pulled into the mechanism causing jamming and possible
gear damage. Proper paper roll supplies are available from Extech as P/N 757060
2.2 Tearing Paper
The printer's paper door acts as a tear bar. Pull one edge of the paper against the tear bar
as indicated, then tear down and across against the tear bar to tear the paper as shown in
Figure 8.
The tear bar may have sharp edges
Note: Using the tear bar is the only way to tear the paper.
Note: Pulling up and pulling sideways without using the tear bar can cause a paper jam due
to paper misalignment in the print head mechanism
1500T User's Guide
FIGURE 7: TEARING PAPER
Rev 2.1
12
