■ Optional HM-168 description
Alligator type clip
To attach the speaker-mc.
to your shrt or collar, etc.
PTT switch
Transmts whle pushed
Receves whle released
Microphone
Speaker
Turn the transcever power OFF
when connectng the HM-168.
NEVER mmerse the connector n water. If the connector becomes
wet, be sure to dry t BEFORE attachng t to the transcever.
NOTE: The mcrophone s located at the top of the speaker-m-
crophone, as shown n the dagram above. To maxmze the
readablty of your transmtted sgnal (voce), hold the mcro-
phone approx. 5 to 10 cm from your mouth, and speak n a nor-
mal voce level.
34

SPEAKER-MICROPHONE
