LIONEL LEGACY CONTROL SYSTEM
C H A R I G N G I N D C I
While Charging The Remote
Slow Alternating Red Charger in preconditioning state
Transition to fast charge when battery voltage reaches 3.0V
Fast alternating red Charger in fast charging state
Transition to top off when battery trend begins to decline
Slow alternating Green Charger in top off state
Transition to complete after 60 min in top off
Solid both Green C a h
Transition Indicator lights go out after remote is removed
ERROR Indications
Recovery is automatic after temp cool to below 30C
Solid both red while in charging cycle Battery temp reaches 55C
Recovery is automatic after temp cools to below 45C
If this condition continues the batteries may be faulty
Both fast blink red while in charging mode The battery voltage exceeds 5.5V
Recovery is accomplished by removing the remote from
charger
Possible indication of the wrong battery type such as
alkaline batteries
Note: If the re-chargable batteries are not charging properly, check the Charger Switch under the Base/Char-
ger to be sure it is set to "ON."
Battery Level Indicator
The Battery Level Indicator is at the upper left side of the CAB-2 Screen.
indicates Battery is charged
cations
Factory antenna specs only, do not exceed these ratings.
This device has been designed to operate with the antennas listed below, and having a maximum gain of
3dB. Antennas not included in this list or having a gain greater than 3dB are strictly prohibited for use with
this device. The required antenna impedance is 50 ohms.
BOBOTO TELECOM INSTRUMENT FACTORY, model no. TLB-2400-3A-RP SMA
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful
communication.
"Clean and Lubricate Your Equipment"
LIONEL LEGACY CONTROL SYSTEM
A T O R L G I H T S C H A R T S
i g r g n c c y e l o c m p e l e t
indicates Battery needs charging
Page 80
"Wipe Your Track Regularly"
LIONEL LEGACY CONTROL SYSTEM
T A B L E
Throughout this manual references to Options are made. In the INFO menu, Options can
be selected. The following Table of Options shows the possibilities that are available to you
in tuning the performance of your LIONEL products. From time to time, more Options may
be added to particular product types.
Remember to visit www.lionel.com regularly for up-to-date advances.
This manual will be updated regularly to include options added for new products. A good
example of options coming in the future would be "RailSounds tuning." Manuals that come
Options tables. Occasionally, future Components and System Revision Memory Modules will
include a new updated manual that is current with the LIONEL LEGACY Control System.
NOTE: Navigating the INFO and OPTION menus can be done with either the Scroll but-
ton or the Velocity Throttle.
ENGINE INFO OPTIONS
RAIL-SOUNDS TYPE
CUSTOM
NO
NAME Assign Name
RS
LOAD Load MM
RS5
AUX Aux Settings
LRS
CLR Clear Name
TYPE
CONTROL
DSL Diesel CAB1
STM Steam
DSW Diesel Switcher
SSW Steam Switcher
ELC Electric
TMCC
SUB Subway
LPD LEGACY Pullmor Diesel
LPS LEGACY Pullmor Steam
ACC Accessory
REL 100
PAS Passenger
BDU Break Down Unit
FRT Freight
LEG
ACLA Acela
CRN Crane/Boom
TRAIN INFO OPTIONS
NAME Name addresses Train
BUILD
CLR Clear the addressed train (road number, Engines in train, name of train, etc.)
"Clean and Lubricate Your Equipment"
LIONEL LEGACY CONTROL SYSTEM
O F O P T O I N S
Look in documentation or box
label for Rail-Sounds version
No Sounds
Rail Sounds 2-4
Rail Sounds 5
LEGACY Rail-Sounds
CAB1 + or - relative speed commands
Mode Lionel Power Masters
Lionel Track Power Controllers
Engine or track settings
Electric RR or EOB Speed Control
TMCC 32 Absolute speeds
Mode Lionel locomotives and accessories
ElectricRR or EOB speed controls
REL 100 100 Relative speed commands
Mode ElectricRR speed controls
Lionel OEM's (with ElectricRR cruise)
LEGACY 200 Absolute speeds
Mode Lionel LEGACY engines
Lionel LEGACY accessories
Page 81
