This chapter provides information for installing and configuring the Compaq
StorageWorks RAID Array 4100.

Materials Needed

IMPORTANT: To take advantage of all features and make sure you have the latest
firmware update, check the Compaq website at www.compaq.com.
To install the Compaq StorageWorks RAID Array 4100, you will need the
following materials:
I
Compaq RA4100
I
Rack mounting hardware
Left and right mounting brackets (supplied)
Mounting screws and cage nuts (supplied)
#2 Phillips screwdriver (not supplied)
I
Compaq Hot Plug Ultra2 Disk Drives (s)
I
Compaq StorageWorks RA4000 Controller (pre-installed)
I
Compaq StorageWorks Fibre Channel Host Adapter/P or Compaq
StorageWorks Fibre Channel Host Adapter/E
I
Compaq StorageWorks Fibre Channel Storage Hub 7 or 12 and
mounting hardware (if required)
2
Chapter

Installation
