3-4 Compaq StorageWorks RAID Array 4100 User Guide
Fan Assembly
The fan assembly LED applies only to that module.
Figure 3-3. Fan Assembly LED
LED
Condition
Status
Green
Amber
Off
Table 3-3
Fan Assembly LED
Fans running normally.
Fault detected in one or more fans.
No power connected to fan array module.
Meaning
