2-2 Compaq StorageWorks RAID Array 4100 User Guide

Installing the RAID Array 4100

I
GigaBit Interface Converter (GBIC) modules (Two GBICs are required
for each Fibre Channel cable installed.)
Short-wave GBIC option kit for use with multi-mode cables
(part number 234459-B21)
Two Short-wave GBICs are provided with each RA4100 and Fibre Host
NOTE:
Adapter.
Long-wave GBIC option kit for use with single-mode cables
(part number 340412-B21)
Single-mode Fibre Channel cables are not provided with this kit. A list of
NOTE:
Fibre Channel cable suppliers can be found at the Compaq website:

www.compaq.com

I
Fibre Channel cable
Multi-mode for distances from 2 meters to 500 meters
2-meter multi-mode cable kit, part number 234457-B21
5-meter multi-mode cable kit, part number 234457-B22
15-meter multi-mode cable kit, part number 234457-B23
Single-mode for distances of more than 500 meters and up to
10 kilometers
I
AC power cord (supplied)
I
Pencil (not supplied)
I
Cage nut installation tool (not supplied)
To install the Compaq StorageWorks RAID Array 4100, you will need to:
1. Choose a location.
2. Install the RA4100 in the rack.
3. Install the hot-pluggable drive(s).
4. Install the Compaq StorageWorks Fibre Channel Storage Hub. Refer to
the documentation supplied with this device for details on installation
and rack mounting.
