VENTED & VENT-FREE GAS LOG
Owner' s Operation and Installation Manual
GLVF24MAN, GLVF24MAP, GLVF24MVN, GLVF24MVP
Vented:
Certified for USA and Canada: ANSI Z21.60/2003, ANSI Z21.60a/2003, ANSI Z21.60b/2004,
If the information in this manual is not followed exactly, a fire or
explosion my result causing property damage, personal injury, or
loss of life.
– Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room
in which it is installed. Provisions for adequate combustion and ventila-
tion air must be provided. Refer to "Air for Combustion and
Ventilation" section of this manual, page 7.)
Save this manual for future reference • 2340 Logan Ave., Winnipeg, MB, Canada, Phone: (204) 632-1962 • Printed in Canada • June 18, 2009 • PART #24GL-MAN
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Vent-free:
Certified to USA standards: ANSI Z21.11.2 - 2007
CSA 2.26/2004, CSA 2.26a/2003,CSA 2.26b/2004
Warning
Warning
This appliance must be installed by a licensed plumber or
gas fitter in the Commonwealth of Massachusetts and meet
the requirements of 527 CMR 30 and 248 CMR.
Improper installation, adjustment,
alteration, service, or maintenance can
cause injury or property damage. Refer
to this manual for correct installation and
operational procedures. For assistance or
additional information consult a qualified
installer, service agency, or the gas supplier.
These gas logs sets are for installation in
a masonry solid fuel burning fireplace, a
U.L. Listed manufactured solid fuel
burning fireplace. The vent free gas log
sets are also AGA design, certified for
vent free Universal Fireboxes.
1
Warning
Warning
Minimum Fireplace Dimensions:
see page 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLVF24MAN and is the answer not in the manual?

Questions and answers

Related Manuals for Kingsman GLVF24MAN

Summary of Contents for Kingsman GLVF24MAN

  • Page 1 VENTED & VENT-FREE GAS LOG Owner’ s Operation and Installation Manual INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. GLVF24MAN, GLVF24MAP, GLVF24MVN, GLVF24MVP Vent-free: Certified to USA standards: ANSI Z21.11.2 - 2007 Vented: Certified for USA and Canada: ANSI Z21.60/2003, ANSI Z21.60a/2003, ANSI Z21.60b/2004, CSA 2.26/2004, CSA 2.26a/2003,CSA 2.26b/2004...
  • Page 3 PRE-INSTALLATION QUESTIONS and ANSWERS Why does my fireplace or stove give off odour? It is normal for your fireplace to give off some odour. This is due to the curing of the paint, adhesives, silicones and any undetected oil from the manufacturing process as well as the finishing materials used with the installations (e.g.

  • Page 4: Table Of Contents

    Fuel Manifold Orifice Primary Rate Min/Max Model Size Type Input Pressure Size Screw Inlet Press. GLVF24MAN 24” Natural Gas 20,000 - 35,000 1.5” - 4.4” 0.218 5.5/10” GLVF24MAP 24” Liquid Propane 24,000 - 30,000 7” - 10” Full Open 11/13”...

  • Page 5: Safety Information

    SAFETY INFORMATION WARNINGS WARNINGS DANGER Important: Read this owner’s manual carefully and com- pletely before trying to assemble, operate, or service this logset. Improper use of this logset can cause serious injury CARBON MONOXIDE POISONING or death from burns, fire, explosion, electrical shock, and MAY LEAD TO DEATH! carbon monoxide poisoning.

  • Page 6: Local Codes

    SAFETY INFORMATION WARNINGS Cont. 15. Isolate the appliance from the gas supply piping system by closing its individual manual shut off valve during any pressure testing of the the gas supply piping system at test pressure equal or less than 1/2 psig. 16.

  • Page 7: Air For Combustion And Ventilation

    AIR FOR COMBUSTION AND VENTILATION Today’s homes are built more energy efficient than ever. New materials, increased insulation, and new construction methods help reduce heat loss in homes. Home owners weather strip and caulk around windows and door s to keep the cold air out and the warm air in.
  • Page 8 AIR FOR COMBUSTION AND VENTILATION Cont. 1. Determine the volume of the space (length x width x height). Length x Width x Height = ______________ cu. ft. (volume of space) Example: Space size 22ft. (length) x 18 ft. (width) x 8 ft. (ceiling height) = 3168 cu. ft. (volume of space) If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of the space.

  • Page 9: Ventilation Air From Inside Building

    AIR FOR COMBUSTION AND VENTILATION Cont. VENTILATION AIR FROM INSIDE BUILDING This fresh air would come from an adjoining unconfined space. When ventilating to an adjoining unconfined space, you must provide two permanent openings: one within 12” of the ceiling and one within 12” of the floor on the wall connecting the two spaces (see options 1 and 2, Figure 4).

  • Page 10: Ventilation Air From Outdoors

    AIR FOR COMBUSTION AND VENTILATION Cont. VENTILATION AIR FROM OUTDOORS Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent openings: one within 12” of the ceiling and one within 12” of the floor. Connect these items directly to the outdoors or spaces open to the outdoors. These spaces include attics and crawl spaces.

  • Page 11: Installing

    INSTALLING – Clearances INSTALLATION Minimum Firebox Width CLEARANCES (VENT FREE APPLICATION ONLY) Minimum Firebox Depth Minimum noncombustible material above fireplace opening must be no less than shown in the figures above. Noncombustible materials (slate, marble, tile, etc.) must be at least 1/2” thick, if sheet metal is used, you must have a non- combustible material behind it.

  • Page 12: Installing Into Existing Fireplace

    INSTALLING INSTALLATION OF GLVF24 INTO WARNING EXISTING FIREPLACE If installing in Canada or as a vented logset: Before installing in a solid fuel burning fireplace, the NOTE: When used as a vented heater, appliance must be chimney flue and firebox must be cleaned of soot, installed only in a solid fuel burning fireplace with a working creosote, ashes, and loose paint by a qualified chimney flue and constructed of non-combustible material.

  • Page 13: Installing Gas Line

    INSTALLING – Gas Line INSTALLING GAS LINE DANGER Early signs of carbon monoxide poisoning resemble the flu, with headaches, dizziness, and / or nausea. If you have these CARBON MONOXIDE POISONING signs, the heater may not be working properly. Get fresh air at once! Turn off gas appliance.
  • Page 14 INSTALLING – Gas Line Cont. regulator. Check pressure at the pressure test point, which is CAUTION located on the side of the gas control near the pilot outlet. Make sure that the pressure tap is completely closed after checking gas pressure. The pressure should be checked with Any safety screen or guard removed for servicing an the appliance burning and the control set on high.

  • Page 15: Cleaning And Servicing Of Burner / Ods Pilot

    INSTALLING – Burner System CLEANING AND SERVICING OF BURNER / ODS PILOT It is recommended to annually inspect and clean the unit to prevent malfunction and / or sooting. This operation should be performed by your dealer or a qualified technician. WARNING Remove log set, handling carefully by holding gently at each end.

  • Page 16: Attaching Log Grate

    2. Place crossover log on locating pins on top of rear main damage or personal injury. log. 3. Position front log flat surface up to main log. ➃ ➁ ➀ Kingsman Replacement Log Listing Reference Part Number Number Description 24F-A Front Main Log A, LOGF24 ➂...

  • Page 17: Installing Logs

    STEP 4 Position log #4 onto rear log holder and pull up to logs 1 and 2. STEP 2 Locate hole on underside of log and place log over burner and Locator Pin and lower into position. ➃ ➁ ➀ ➂ Kingsman Replacement Log Listing Reference Part Number Number Description 18F-C...
  • Page 18 LOGF30 LOG INSTALLATION 1) Align front hole of log support plate with original log locator pin. 2) Slide log support over pin & using two 10-24 DT screws, mount plate LOG LOCATOR TAB to burner grate. NOTE: Make sure log support is tight LOG SUPPORT against side of burner grate before fastening.
  • Page 19 STEP #5 & 6. Line up holes on crossover logs with locator of log with Tab on support bracket and lower into position. pins on rear log #4 and lower into position. ➄ ➅ ➁ Kingsman Replacement Log Listing Reference Part Number Number Description...

  • Page 20: Millivolt Lighting Instructions

    MILLIVOLT LIGHTING INSTRUCTIONS CAUTION Do not wire 120 Volt power to Millivolt switches or thermostats. WARNING FIGURE 12 – Millivolt Models If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 21: Illustrated Parts List

    ILLUSTRATED PARTS LIST VENT FREE 24” LOG SET PARTS AND ASSEMBLY with SIT Nova Valve Models: GLVF24MVN, GLVF24MVP Part Numbers for: No. GLVF24MVN GLVF24MVP Description 33VF-113 33VF-113 Oxygen Depletion Shield 24GL-101 24GL-101 Log Holder 33VF-P8214 33VF-P8214 ODS Pilot 33VF-P637SI 33VF-P637SI ODS Valve 6000-112 6000-112...
  • Page 22 ILLUSTRATED PARTS LIST Cont. VENT FREE 24” LOG SET PARTS AND ASSEMBLY with SIT Euro-Valve Models: GLVF24MAN, GLVF24MAP Part Numbers for: No. GLVF24MAN GLVF24MAP Description 24GL-105 24GL-105 Bottom Burner Pan 33VF-106 33VF-106 Pilot Bracket 33VF-113 33VF-113 Oxygen Depletion Shield 24GL-101...
  • Page 23 ILLUSTRATED PARTS LIST Cont. VENTED 24” LOG SET PARTS AND ASSEMBLY with SIT Nova Valve Models: GLV24MVN, GLV24MVP Part Numbers for: No. GLV24MVN GLV24MVP Description 24GL-105 24GL-105 Bottom Burner Pan 33VF-106 33VF-106 Pilot Bracket 24GL-101 24GL-101 Log Holder 1001-P606SI 1001-P606SI Pilot 1001-634SI 1001-633SI...
  • Page 24 ILLUSTRATED PARTS LIST Cont. VENTED 24” LOG SET PARTS AND ASSEMBLY with SIT Nova Valve Models: GLV24MAN, GLV24MAP Part Numbers for: No. GLVF24MAN GLVF24MAP Description 24GL-101 24GL-101 Log Holder 1001-P606SI 1001-P605SI Pilot 33VF-P522SI 33VF-P522SI ODS Valve 24GL-104 24GL-104 Valve Bracket...

  • Page 25: Troubleshooting

    TROUBLESHOOTING WARNING Turn off and let cool before servicing. Only a qualified NOTE: all troubleshooting items are listed in order of service person should service and repair heater. operation. When igniter button is pressed, there is no spark at ODS/Pilot. Remedy Possible Cause 1.
  • Page 26 TROUBLESHOOTING Cont. 5. Pilot flame not touching thermocouple, which allows 5. Contact local gas company. thermocouple to cool, causing pilot flame to go out. Problem could be caused by one or both of the following: A) Low gas pressure B) Dirty or partially clogged ODS/pilot. 6.

  • Page 27: Limited Lifetime Warranty

    During the first year after installation, we will provide a replacement for any component part of your unit found to be defective in materials or workmanship, including labour costs. Repair work requires prior approval by Kingsman, labour costs are based on a predetermined rate schedule and any repair work must be done through an authorized Kingsman dealer.
