Uponor Controller C-33 layout
Pos. Description
1
Connectors for 1–8 actuators
2
Connectors for 1–6 thermostats
3
230 V AC compartment
C-33 wiring diagram
UPONOR CONTROL SYSTEM WIRED - INSTALLATION AND OPERATION MANUAL
Pos. Description
4
Power indicator
• Red = Power on (heating mode)
• Off = Power off
