Purelink DOF-T2.0 User Manual V1.1
DOF-T2.0
4K60 DisplayPort and USB 2.0 Fiber Extender System
USER MANUAL
PureLink
220-10 State Route 208
Fair Lawn, NJ 07410 USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com.
Advertisement
Table of Contents
Related Manuals for PureLink DOF-T2.0
Summary of Contents for PureLink DOF-T2.0
- Page 1 Purelink DOF-T2.0 User Manual V1.1 DOF-T2.0 4K60 DisplayPort and USB 2.0 Fiber Extender System USER MANUAL PureLink 220-10 State Route 208 Fair Lawn, NJ 07410 USA Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com For order support, please contact your local dealer.
-
Page 2: Table Of Contents
Product Features............................3 Package Contents ............................3 Specifications ..............................4 Operation ..............................5 Installation..............................5 DOF-T2.0 Transmitter Panel View ....................... 5 DOF-T2.0 Receiver Panel View ......................6 LED Indicators ............................6 DisplayPort ............................6 Other signal extensions ......................... 6 Dip Switch Settings ........................... 7 RS232 ................................ -
Page 3: Introduction
DisplayPort 4K/60 video, audio, and control signals over fiber. Ultra HD/4K, HDMI 2.0 (18G), embedded audio, RS-232, and bi-directional IR are all supported over distances up to 3,300 ft. using PureLink’s TOTALWIRE LC-terminated fiber optic cables. The pure fiber connection provides protection from electromagnetic interference (EMI), delivering lossless transport for optimal signal quality. -
Page 4: Specifications
Purelink DOF-T2.0 User Manual V1.1 Specifications Inputs: (1) DisplayPort Type A female Connector Type/s (Tx) Outputs: (1) SFP 10G+ Fiber module Control: (1) DB9 female [RS-232], (2) 3.5mm jack [IR Input/Output] Inputs: (1) SFP 10G+ Fiber module Connector Type/s (Rx) Outputs: (1) DisplayPort Type A female Control: (1) DB9 male [RS-232], (2) 3.5mm jack [IR Input/Output]... -
Page 5: Operation
Purelink DOF-T2.0 User Manual V1.1 Operation Installation Please note: the working distance is subject to the type of Fiber Optic cable used and the type of transceiver used. The product comes with 10G SFP+ 2LC Single Mode Fiber modules which can provide up to 2000 meters of extension when used with quality single mode fiber cabling. -
Page 6: Dof-T2.0 Receiver Panel View
Purelink DOF-T2.0 User Manual V1.1 DOF-T2.0 Receiver Panel View LED Indicators When the Green LED is on = unit is getting power • When the Blue LED is on = Fiber link between transmitter and receiver is connected • DisplayPort Connecting a DisplayPort cable with a valid signal at the input of the Transmitter will automatically establish the connection through to the Receiver. -
Page 7: Dip Switch Settings
Purelink DOF-T2.0 User Manual V1.1 Dip Switch Settings Switch Function SW 1 IR Extender Function RS232 Extender Function USB Keyboard SW 2 Mouse Extender Function SWITCH position 1 and 2 must be positioned as above instructed above: IR: SW1 ON (down position) + SW2 OFF (up position) -
Page 8: Warranty
TERMS & CONDITIONS PureLink shall repair or replace the Product if it develops a material fault during the period of warranty, on condition that i) the Product has only been subject to normal use in a domestic or commercial environment in a manner consistent with its... -
Page 9: Customer Service
Most problems can be corrected over the phone through close cooperation between Customer and a PureLink technician. To better enable PureLink to address a warranty claim, please have the Product’s serial and model numbers. If PureLink, in its sole discretion, determines that an on-site visit or other remedial action is necessary, PureLink may send a representative to Customer’s site.
