PureLink DTS-1000RV Owner's Manual

Dts-1000rv: dvi/hdmi or vga, audio, rs-232c transmitter extender drs-1000rv: dvi/vga or vga, audio, rs-232c receiver extender

Advertisement

Quick Links

DTS/DRS-1000RV
Owner's Manual
DTS-1000RV: DVI/HDMI or VGA, Audio, RS-232C
Transmitter Extender
DRS-1000RV: DVI/VGA or VGA, Audio, RS-232C
Receiver Extender
Dtrovision LLC
9A Bergen Turnpike
Little Ferry, NJ 07643
Tel: 201.488.3232
Fax: 201.621.6118
www.purelinkav.com
E-mail:
sales@dtrovision.com
For technical support, contact:
support@dtrovision.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTS-1000RV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PureLink DTS-1000RV

  • Page 1 DTS/DRS-1000RV Owner’s Manual DTS-1000RV: DVI/HDMI or VGA, Audio, RS-232C Transmitter Extender DRS-1000RV: DVI/VGA or VGA, Audio, RS-232C Receiver Extender Dtrovision LLC 9A Bergen Turnpike Little Ferry, NJ 07643 Tel: 201.488.3232 Fax: 201.621.6118 www.purelinkav.com E-mail: sales@dtrovision.com For technical support, contact: support@dtrovision.com...
  • Page 2: Package Contents

    Package Contents Please make sure all of the following items are included in the package: 1) DTS-1000RV Transmitter Module or DRS-1000RV Receiver Module x 1 *The transmitter module and the receiver module are sold separately* 2) DC 12V power supply unit x 1 3) AC cord x 1 4) Owner’s Manual x 1...
  • Page 3: General Specification

    CAT5 cables, making this system a convenient and affordable solution for transmitting high-quality digital and analog video, as well as audio signals in various applications. Item Description Model DTS-1000RV/DRS-1000RV DVI/HDMI VGA( D-Sub) Input Signal Stereo Audio (3.5mm mini jack) x 2 RS-232...
  • Page 4: Operation And Reliability Specification

    Operation and Reliability Specification 1. Operating Environment Temperature : 50F ~ 104F (10℃~ 40℃) Humidity : 10% ~ 80% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃) Humidity : 5% ~ 95% Altitude : 15,000m Max. 3.
  • Page 5: Main Features

    3. Compact and durable design DTS-1000RV/DRS-1000RV is comes in compact and robust 1RU size design. 4. Fiber optic cable for long distance signal transmission Long Distance (Up to 5000ft at 1080i or lower signal) over cost effective multimode fiber optic cables.
  • Page 6: Installation And Connection Instructions

    TX : 3 -> RX : 3 , TX : 4 -> RX : 4 CAT5 cable DTS-1000RV/DRS-1000RV is designed to conform to TIA/EIA-568-B standards. Check whether the PIN MAP is properly connected to the TIA/EIA-568-B (as illustrated below) before use. (Note: CAT-5E or CAT-6 cables will deliver signal for longer distances).
  • Page 7 Brown RS-232 Connection Set up connection in the order illustrated below before use.
  • Page 8 PRODUCT DIMENSION Exterior Dimension (W*D*H): 4.3’x5.1’x1.6 mm, 1.4 lbs per unit DTS-1000RV : DVI/HDMI or VGA, Audio, RS-232C Transmitter Module...
  • Page 9 DTS-1000RV DVI/HDMI Fiber Optic Extension Module Transmitter DRS-1000RV : DVI/HDMI or VGA, Audio, RS-232C Receiver Module...
  • Page 10: Front Panel

    DRS-1000RV DVI/HDMI Fiber Optic Extension Module Receiver Front Panel: PWR: Power LED ST: Signal LED MODE: EDID Setting EDID S/W: EDID Save button Rear Panel: DVI Input (Tx), DVI Output (Rx) VGA Input (Tx), VGA Output (Rx) DVI or VGA Dip switch (Only on Tx side) Optical In /Out ports: Fiber optic connection Audio In (Tx), Audio Out(Rx) :3.5mm Stereo Audio Jack CONTROL (For RS-232): CAT5...
  • Page 11: User Guide

    D-HD1080p (2CH) , E-HD1080p(Multi) Saving external EDID DATA: Connect display (monitor or display) to the DTS-1000RV transmitter. Set your rotatory switch to “ 0 “, then press the EDID S/W button. Transmitter will read and save the EDID data on the internal EEPRom.
  • Page 12: Technical Specification

    Technical Specification Data Transfer Speed: Up to 2.25 Gbps (Single Link) Frequency Range: 25 ~ 165 MHz Supporting Display Resolutions: Up to WUXGA (1920X1200)@60Hz / 1080p I/O Signal Standard: Digital RGB, VGA, Stereo Audio (3.5mm), RS-232 Max Distance: 1,000m (3,300ft) at 1920x1200@60Hz / 1080p 1,500m (5,000ft) at 1600x1200@60Hz / 1080i Optical Source: 850 nm Vcsel...
  • Page 13: Warranty

    Warranty 2 (two) Year Warranty Dtrovision warrants this DTS-1000RV/DRS-1000RV fiber optic extender to be free from defects in workmanship and materials, under normal use and service, for a period of two (2) year from the date of purchase from Dtrovision or its authorized resellers.
  • Page 14: Fcc/Ce Statement

    FCC/CE Statement This device complies with part 15 of FCC Rules and EN 55022/55024/61000-3 for CE certification. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must not accept any interference received, including interference that may cause undesired operation.
  • Page 15 UL Statement This device has completed a UL Commercial Inspection and Testing Services for the multimode HDMI cable complied with VW-1 under UL 758. It is validated by the UL file number SV2038 and project number 04CA05353.

This manual is also suitable for:

Drs-1000rv
