EPSON AcuLaser C1900/AcuLaser C900

4.1.2 Tools

Use only specified tools to avoid damaging the printer.
Table 4-1. Tools
Name
Phillips screwdriver No. 1
Phillips screwdriver No. 2
Mini Phillips screwdriver
Slotted screwdriver
Disassembly and Assembly
Commercial Code
Availability
Available B743800100
Available B743800500
Available B743000100

4.1.3 Screws

Ref. No. Nominal
Size
1305 3×6
+ Pan Head Screw - with Spring
Washer and Plain Washer
(Sems)
1308 3×8
3501 3×6
+ Cup Screw
3504 3×8
3907 3×8 + Bind B-tite Screw
1112 3×6
+ Bind S-tite Screw
3704 3×8
+ Cup B-tite Screw
Overview
Table 4-2. Screws
Name and Specification
Revision B
Appearance
169
