INSTALLATION MANUAL
DIRECT VENT GAS FIREPLACE
English and French Installation Manuals Available Through Your Local Dealer or Visit Our Website at www.kozyheat.com
Les manuels d'installation en anglais et en français sont disponibles chez votre détaillant local ou en visitant notre site Web : www.kozyheat.com
IMPORTANT:
This installation manual is to be used in conjunction with SUPPLEMENTAL
INSTALLATION AND HOMEOWNER INFORMATION MANUAL. Read both manuals before installing
and operating appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located,
manufactured home (USA only) or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases, unless a certified kit is used.
WARNING: If the information in these instructions is not followed exactly, a fire
or explosion may result causing property damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity
—
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
◙ Do not try to light any appliance.
◙ Do not touch any electrical switch: do not use any phone in your building.
◙ Immediately call gas supplier from a neighbors phone. Follow the gas supplier
instructions.
◙ If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
WARNING
HOT GLASS WILL CAUSE BURNS.
DO NOT TOUCH GLASS UNTIL COOLED.
NEVER ALLOW CHILDREN TO TOUCH GLASS.
www.kozyheat.com
Report No. 216-S-37b-6.5
JULY 2013
ALP-36-L-REV-04
Advertisement
Chapters
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for kozy heat Alpha ALP-36-L
Summary of Contents for kozy heat Alpha ALP-36-L
- Page 1 — Installation and service must be performed by a qualified installer, service agency or the gas supplier. WARNING HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. Report No. 216-S-37b-6.5 JULY 2013 ALP-36-L-REV-04 www.kozyheat.com...
- Page 2 INTRODUCTION Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. CONGRATULATIONS! We welcome you as a new owner of a Kozy Heat gas fireplace. Kozy Heat products are designed with superior components and materials and assembled by trained craftsmen who take pride in their work.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION VENTING (cont.) Introduction and Homeowner Reference Information Horizontal Termination Minimum / Maximum CONTENTS Horizontal & Vertical Combination Venting Illustrations Table of Contents #800-1 Series Flex Vent Installation Instructions 21-22 SAFETY INFORMATION Termination Vent Cap Location Safety Information Vent Termination Clearances COMMONWEALTH OF MASSACHUSETTS INFORMATION LIGHT KIT... -
Page 4: Safety Information
SAFETY INFORMATION This fireplace has been tested by OMNI-Test Laboratories, Portland, Oregon and complies with: ANSI Z21.88-2009/CSA 2.33-2009, “Standard for Vented Gas Fireplace Heaters.” CAN/CGA 2.17-M91 (R2009), “Gas-Fired Appliances for Use at High Altitudes”. CAN/CSA P.4.1-09, “Testing Method for Measuring Annual Efficiency”. This installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1 The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, wth the National... - Page 5 COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS NOTE The following requirements reference various Massachusetts and national codes not contained in this manual. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS...
-
Page 6: Specifications
SPECIFICATIONS FIREPLACE DIMENSIONS FIREPLACE DESCRIPTION Height Width Back Width Depth Opening Glass Frame Top Stand-off Back to vent Width Height Height center DIMENSIONS INCHES 41-11/16 46-1/2 41-11/16 23-3/8 38-3/8 5-5/16 9-3/8 MILLIMETERS 1059 1182 1059 All stand-off brackets must be attached to fireplace. Do not remove. Top stand-off brackets are not load bearing. Non-combustible zone: Top stand-offs provide 5-5/16”... -
Page 7: Additional Components Required
SPECIFICATIONS ADDITIONAL COMPONENTS REQUIRED Vent System: Approved venting listed on page 17 of this installation manual. INSTALLATION OVERVIEW NOTE The qualified installer should follow the procedure best suited for the installation. Frame an opening for fireplace, allowing for vent installation and type of installation (corner or flat wall application). If masonry (optional) is used, prepare foundation for the masonry load. -
Page 8: Placement Clearance Requirements
SPECIFICATIONS PLACEMENT CLEARANCE REQUIREMENTS This fireplace must be installed on a level surface capable of supporting fireplace and venting. Fireplace must be placed directly on wood or non-combustible surface (not linoleum or carpet) extending entire depth and width of fireplace. Due to high surface temperatures, fireplace should be located out of traffic and away from furniture and draperies. -
Page 9: Fireplace Preparation
FIREPLACE PREPARATION STAND-OFF / STAND-OFF HEAT SHIELD ASSEMBLY & INSTALLATION Top and back stand-off brackets must be formed and attached prior to positioning fireplace into framed opening. Top stand-offs provide 5-5/16” (135mm) minimum clearance to header. Use only non-combustible material in this area for entire WARNING width of fireplace. -
Page 10: Nailing Flange Assembly & Installation
FIREPLACE PREPARATION NAILING FLANGE ASSEMBLY & INSTALLATION Remove (4) nailing flanges from fireplace sides. With the 1/2” (13mm) long stand-offs on nailing flanges facing away from fireplace, align nailing flange with holes on outside corners of fireplace. Secure with screws (provided in components packet) through slots in nailing flanges. Bend perforation on nailing flange until parallel with fireplace face. -
Page 11: Framing
FRAMING WALL ENCLOSURE ROUGH OPENING Determine whether wall surface will be flush with fireplace face (wall and fireplace face will be covered with non-combustible material such as tile) or, framing will be flush with fireplace face, which results in a flat wall appearance. IMPORTANT Framing dimensions should allow for wall covering thickness and fireplace facing materials. -
Page 12: Vertical Terminations
FRAMING Determine exact position of your fireplace, including hearth height, width, and depth, (if applicable). If possible, place fireplace in such a manner that vent termination will be placed between two studs, eliminating the need for additional framing. If masonry is to be used (optional), prepare necessary foundation for the masonry load. When masonry construction is being used, a lintel must be used over top of fireplace to support the added weight. -
Page 13: Facing And Finishing
FACING AND FINISHING This fireplace was designed to accommodate non-combustible facing material up to 1/2” (13mm) thick. Install non-combustible facing material up to facing flange surrounding the glass frame assembly. Do not apply any material beyond this point. The glass frame assembly must be removable. -
Page 14: Typical Installation Options
TYPICAL INSTALLATION OPTIONS Kozy Heat wall pass-thru (#800-WPT or #800-WPT2) must be used on all horizontal vent runs. The horizontal heat shield included with this fireplace must be installed when incorporating minimum horizontal venting. IMPORTANT This applies to Nat. and LP minimum horizontal venting configurations. Horizontal vent heat shield not shown in illustrations below for clarity purposes only. -
Page 15: Mantel Requirements
MANTEL REQUIREMENTS Non-combustible zone: No combustible materials allowed on top of fireplace within shaded area for entire width and depth WARNING of fireplace with the exception of the header. Figure 14a... -
Page 16: Hearth Plate / Component Access Doors
HEARTH PLATE / COMPONENT ACCESS DOORS INSTALL HEARTH PLATE / COMPONENT ACCESS DOORS Install glass frame assembly. Install component access doors by rotating bottoms toward center of fireplace far enough to insert mounting studs at top of glass valance through hole at top of access door. Lower bottom into position. Install hearth plate, making sure long angled flange sits behind access door handles, securing in place. -
Page 17: Gas Line Connection
GAS LINE CONNECTION GAS CONVERSION This fireplace is manufactured for use with Natural Gas. Follow instructions included with conversion kit if converting to LP gas. The conversion shall be carried out in accordance with the requirements of the provincial authorities having jurisdiction and in ATTENTION accordance with the requirements of the ANSI Z223.1 installation code. -
Page 18: Venting
VENTING IMPORTANT Consult the local and national installation codes to assure adequate combustion and ventilation air is available. This fireplace is designed to be used with any of the following vent systems without the use of an additional adaptor. Refer to vent manufacturer's installation manual for complete installation instructions. Installation must conform with venting requirements and restrictions as outlined in this manual. -
Page 19: Vertical Vent System Clearances
VENTING VERTICAL TERMINATIONS TERMINATION CAP VERTICAL VENT SYSTEM CLEARANCES ALL SIDES MINIMUM: 4ft. (1.22m) MAXIMUM: 50ft. (15.24m) 1 inch (25mm) ALL APPROVED VERTICAL PIPE MIN. / MAX. VERTICAL VENTING MINIMUM: 4ft. (1.22m) + cap. MAXIMUM: 50ft. (15.24m) + cap. Figure 18a HORIZONTAL VENT SYSTEM CLEARANCES BOTTOM SIDES... - Page 20 VENTING #800-WPT WALL PASS-THRU #800-WPT or #800-WPT2 Wall Pass-Thru must be used on all horizontal vent runs. IMPORTANT This includes both interior and exterior walls. Follow instructions below. FRAMING DIMENSIONS FOR #800-WPT KOZY HEAT WALL PASS-THRU 12-1/2” (318mm) HIGH x 10-7/8” (276mm) WIDE WARNING MAINTAIN ALL CLEARANCES AS STATED IN THIS INSTALLATION MANUAL.
-
Page 21: Horizontal & Vertical Combination Venting Illustrations
VENTING HORIZONTAL TERMINATIONS MINIMUM: TERMINATION CAP 18” (457mm) min. vertical rise / 9” (229mm) min. horizontal + cap. HORIZONTAL VENT MAXIMUM: HEAT SHIELD 18” (457mm) min. vertical rise / 20ft. (6.1m) max. horizontal + cap. 90° ELBOW HORIZONTAL RUN VERTICAL RISE Figure 20a HORIZONTAL &... - Page 22 VENTING INSTALLATION OF #800-1 SERIES DIRECT VENT TERMINATION KIT(S) The flex pipe is permanently attached to the exterior plate. DO NOT ATTACH #844-1 or #845-1 termination kit to fireplace IMPORTANT (or extension kit ) until it has passed through wall. Install termination plates to outside wall exterior. HORIZONTAL TERMINATIONS Refer to illustration on following page.
- Page 23 VENTING FLEXIBLE #800-1 SERIES cont. TERMINATION BOX MOUNTING HOLES IN EXTERIOR WALL PLATE 5” FLEX PIPE COLLAR 5” PIPE ON FIREPLACE OR EXTENSION KIT 8” FLEX PIPE COLLAR 8” PIPE ON FIREPLACE OR EXTENSION KIT VINYL SIDING PROTECTOR (not shown) INTERIOR FIRESTOP Figure 22a...
-
Page 24: Termination Vent Cap Location
TERMINATION VENT CAP LOCATION This gas appliance must not be connected to a chimney serving any other appliance. Terminations against vinyl siding must use a vinyl siding protector. Follow instructions included. DO NOT RECESS TERMINATION KIT INTO OUTSIDE BUILDING MATERIALS - i.e.: brick, stone, siding, etc. If necessary, extend framing so that termination kit will be exposed once building materials are installed. -
Page 25: Vent Termination Clearances
VENTING (Vertical Cap Requirements) VENT TERMINATION CLEARANCES Roof Pitch H (Min.) Ft. H (Min.) m Flat to 6/12 0.30 Over 6/12 to 7/12 1.25 0.38 Over 7/12 to 8/12 0.46 Over 8/12 to 9/12 0.61 Over 9/12 to 10/12 0.76 Over 10/12 to 11/12 3.25 0.99... - Page 26 LIGHTS CAUTION Disconnect all electric power from fireplace before performing this task. NOTE To avoid damage and prolong the life of halogen bulbs, never touch with bare hands. Always use a soft cloth when handling. Remove glass frame assembly. Page 15. Remove light access panel at inside top of firebox - secured with (2) screws.
-
Page 27: Firebox Liner Kit Installation
FIREBOX LINER KIT INSTALLATION FIRE RISK! DO NOT OPERATE THIS FIREPLACE WITHOUT A FIREBOX LINER KIT INSTALLED! WARNING Brick refractory panels act as insulation panels. Enamel panel kits include insulation panels for back and side walls. NOTE If converting to LP Gas, do so now before installing Firebox Liner Kit. Brick Refractory Firebox Liner Kits include: (3) pc. - Page 28 #AL36-500 LOG SET INSTALLATION Numbers are located on the bottom of each log. Install in numerical order. NOTE Refer to following instructions and illustrations for proper placement. Do not place logs directly over burner port holes. CAUTION Improper log placement may affect flame appearance and cause excessive soot to build up on logs and glass. Figure 27a Align holes in bottom of #1-#3 logs with mounting pins on burner, setting down into position.
-
Page 29: Finalizing The Installation
FINALIZING THE INSTALLATION FLAME APPEARANCE: Flame appearance is affected by several factors including altitude, venting configuration and fuel quality. Although the venturi setting has been factory set, adjustments may be necessary for optimal performance and visual aesthetics. When fireplace is first lit, the flames will be blue. Flames will gradually turn yellowish-orange during first 15 minutes of operation. If flames remain blue, or become dark orange with evidence of sooting (black tips), the burner tube venturi may need adjustment. -
Page 30: Restrictor Troubleshooting / Installation After Termination Completion
FINALIZING THE INSTALLATION RESTRICTOR USAGE: Turn fireplace on and allow to burn for 15 minutes. If flames indicate there is excessive draft (flickering, short flames), a restrictor may be necessary. If flames indicate insufficient draft (lifting or ghosting flames), a previously installed restrictor may need to be modified or removed. TO AVOID PROPERTY DAMAGE OR PERSONAL INJURY, ALLOW FIREPLACE AMPLE TIME TO COOL BEFORE MAKING ANY WARNING ADJUSTMENTS AND / OR INSTALLATIONS. -
Page 31: Maintenance
MAINTENANCE The appliance is required to be inspected at least once a year by a professional service person. The compartment below firebox must be cleaned at least once a year, more frequent cleaning may be required due to excessive lint from carpeting, bedding materials, or other fibrous materials. - Page 32 LIMITED WARRANTY KOZY HEAT LIMITED 10 YEAR WARRANTY This limited 10 Year Warranty will not become effective until the Warranty Registration Form has been completed and mailed to Hussong Manufacturing Co., Inc., P.O. Box 577, Lakefield, MN 56150. This registration form must be received within 30 days of installation.
-
Page 33: Lifetime Warranty
LIFETIME WARRANTY LIFETIME WARRANTY THIS LIFETIME WARRANTY COVERAGE WILL BE EXTENDED AS DESCRIBED BELOW PROVIDED ALL WARRANTY CONDITIONS AND REQUIREMENTS ARE MET AS OUTLINED IN THE 10 YEAR LIMITED WARRANTY POLICY. LIFETIME WARRANTY COVERAGE LIFETIME WARRANTY IS EXTENDED AS FOLLOWS: Hussong Manufacturing Co., Inc. warranties to the original purchaser that the firebox, heat exchanger, fiber logs, burner tube and glass panel of this Kozy Heat Fireplace will not be defective in materia l or workmanship under normal use and service for as long as you own this product. - Page 34 — Installation and service must be performed by a qualified installer, service agency or the gas supplier. WARNING HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. Report No. 216-S-37b-6.5 JAN 2013 ALP-36-L-SUP-REV-03 www.kozyheat.com...
- Page 35 TABLE OF CONTENTS SAFETY INFORMATION Safety Information SPECIFICATIONS Components List Gas Pressure Requirements / BTU’s WIRING SCHEMATICS Wiring Schematics OPERATING INSTRUCTIONS Control System Components System Operations Lighting and Shutdown 10-11 Pressure Testing TROUBLESHOOTING Troubleshooting 13-14 #970 HEAT DUCT KIT (OPTIONAL) #970 Heat Duct Kit (optional) 15-17 CONVERSION KIT INSTRUCTIONS...
-
Page 36: Safety Information
SAFETY INFORMATION This fireplace has been tested by OMNI-Test Laboratories, Portland, Oregon and complies with: ANSI Z21.88-2009/CSA 2.33-2009, “Standard for Vented Gas Fireplace Heaters” CAN/CGA 2.17-M91 (R2009), “Gas-Fired Appliances for Use at High Altitudes” CAN/CSA P.4.1-09, “Testing Method for Measuring Annual Efficiency” This installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1 The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, wth the National... -
Page 37: Specifications
SPECIFICATIONS COMPONENTS LIST PART NUMBER DESCRIPTION AL36-L-150 Control Board Assembly 700-203 Manual Gas Shut-off Valve AL36-500 Log Set AL36-L-135 Burner Assembly AL36-CAD Component Access Doors AL36-HP Hearth Plate AL36-LKT Light Kit AL36-028 Fan Kit AL36-057T Glass Frame Assembly 700-408 Remote Control 600-002 Double Receptacle Assembly 942-085... -
Page 38: Wiring Schematics
WIRING SCHEMATICS THIS SYSTEM REQUIRES ELECTRICITY (120V) AND / OR BATTERIES TO OPERATE. IMPORTANT USING BATTERY BACK UP WILL OPERATE BURNER ONLY. FAN AND LIGHT COMPONENTS WILL NOT FUNCTION ON BATTERY BACK-UP POWER. Figure 4a... -
Page 39: Control System Components
CONTROL SYSTEM COMPONENTS REMOTE CONTROL Blue back lit LCD display ON /OFF Key Thermostat Key UP / DOWN Arrow Key Key Lock Mode Key Low Battery Alarm Transmission Thermostat OFF/ON/SMART Room Temperature CPI Mode Set Point Temperature/Level/State Flame ON Figure 5a Lights (not available in all fireplace models) GAS VALVE Stepper motor... -
Page 40: System Operations
SYSTEM OPERATION INITIALIZING THE SYSTEM FOR THE FIRST TIME Set ON/OFF rocker switch to OFF position. Install 4 AA batteries (included in components packet) into battery backup holder. LEDs Connect IFC Control Module to AC power supply. Install 3 AAA batteries (included in components packet) into remote control battery bay (located on base of remote control). - Page 41 SYSTEM OPERATION ROOM THERMOSTAT (Remote Control Operation) The remote control can operate as a room thermostat. The thermostat can be set to desired temperature to control a rooms comfort level. To activate this function, press the Thermostat Key. The LCD display will change to show the room thermostat is ON and set temperature is now displayed.
- Page 42 SYSTEM OPERATION LOW BATTERY DETECTION REMOTE CONTROL: Remote control battery lifespan depends on various factors including battery quality, number of ignitions, changes to room thermostat set point, etc. When remote control batteries are low, a Battery Icon will appear on the LCD display before all battery power is lost.
- Page 43 SYSTEM OPERATION S .I .T. PRO FL A ME 2 I FC I G NI T I O N AND RE S E T I NFO RMAT I O N IGNITION SEQUENCE Starting from OFF, press remote control ON button. Approximately (4) seconds after ON/OFF button is pushed, the IFC control module will start the spark.
-
Page 44: Lighting And Shutdown
LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE OPERATING IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, WARNING CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. 1. This appliance is equipped with an ignition device which automatically lights the pilot. DO NOT try to light the pilot by hand. 2. - Page 45 LIGHTING AND SHUTDOWN (cont.) OPERATING INSTRUCTIONS Read safety information on previous page and front STOP! c o v e r o f t h i s m a n u a l b e f o r e c o n t i n u i n g . Turn off all electric power to the appliance.
-
Page 46: Pressure Testing
PRESSURE TESTING Pressure check taps for manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure IMPORTANT tap marked OUT measures outgoing pressure and the pressure tap marked IN measures incoming pressure. Follow instructions below for proper testing procedures. Refer to page 16 for proper NAT and LP manifold pressures. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa). -
Page 47: Troubleshooting
TROUBLESHOOTING ATTENTION TROUBLESHOOTING MUST BE PERFORMED BY A QUALIFIED TECHNICIAN. Before proceeding with the steps in the following troubleshooting guide, verify the power supply is present and receiver batteries and/or battery pack are fresh and installed with correct polarity. Make sure all connections between wire harnesses and system components are proper and positive. Make sure communication link between remote control and IFC control module is established. - Page 48 TROUBLESHOOTING PILOT AND BURNER EXTINGUISH WHILE IN OPERATION No LP in tank. Check and refill if necessary. Glass frame assembly not installed correctly. Refer to corresponding instructions in this manual. Improper vent cap installation. Adjust if necessary. Vent cap blockage. Remove debris if necessary. Improper pitch on horizontal vent.
- Page 49 #970 HEAT DUCT KIT INSTRUCTIONS CAUTION Read and follow instructions carefully prior to and during installation of this optional heat duct kit. INSTALLATION OF THIS DUCT KIT & ELECTRICAL WIRING MUST BE PERFORMED BY A QUALIFIED SERVICE PERSON AND IN ACCORDANCE WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL ELECTRICAL CODE, ANSI/ WARNING NFPA 70, OR THE CANADIAN ELECTRICAL CODE, CSA C22.1.
-
Page 50: 970 Heat Duct Kit (Optional)
#970 HEAT DUCT KIT INSTRUCTIONS INSTALL REGISTER MOUNTING FRAME, JUNCTION BOX, RUN WIRING Register mounting frame and fan housing are designed to fit between 2” x 4” stud walls, 16” (406mm) on center. Additional framing is required if larger opening exists. Fan motor on heat duct kit may be on opposite side of fan shown in photos. - Page 51 #970 HEAT DUCT KIT INSTRUCTIONS RUN DUCT PIPE Run duct pipe to register location. If oval pipe will be used in conjunction with 6” (152mm) round duct pipe, shape round duct pipe to fit outside oval duct pipe. Secure with screws provided. If oval duct pipe has not been used, shape 6”...
-
Page 52: Conversion Kit Instructions
CONVERSION KIT INSTRUCTIONS #LCK-AL36L-S LP GAS CONVERSION KIT #NCK -AL36L-S NAT GAS CONVERSION KIT This conversion kit shall be installed by a qualified service agency in accordance with the manufacturers instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or productions of carbon monoxide may result, causing property damage, personal injury or loss of life. - Page 53 CONVERSION KIT INSTRUCTIONS CONVERT THE GAS CONTROL VALVE: F ol lo w s t epp e r mot or p r e ss u r e r e gu l a tor in st ru c tio n s h e e t in c lud ed wi th con ver s ion kit to con ve rt ga s va l ve . (LP or NAT marked on stepper motor pressure regulator).
- Page 54 FINALIZING THE INSTALLATION FLAME APPEARANCE: Flame appearance is affected by several factors including altitude, venting configuration and fuel quality. Although the venturi setting has been factory set, adjustments may be necessary for optimal performance and visual aesthetics. When fireplace is first lit, the flames will be blue. Flames will gradually turn yellowish-orange during first 15 minutes of operation. If flames remain blue, or become dark orange with evidence of sooting (black tips), the burner tube venturi may need adjustment.
-
Page 55: Maintenance
MAINTENANCE MAINTENANCE The appliance is required to be inspected at least once a year by a professional service person. The compartment below firebox must be cleaned at least once a year, more frequent cleaning may be required due to excessive lint from carpeting, bedding materials, or other fibrous materials. - Page 56 1-1/8” Glass gasket w/ adhesive AL36-057T Valance with 37” (940mm) x 32” (813mm) glass FAN KIT AL36-028 Fan Kit MISCELLANEOUS AL36- CAD Component Access Doors AL36-HP Hearth Plate Hussong Manufacturing Co., Inc. P.O. Box 577 204 Industrial Park Drive Lakefield, MN 56150-0577 www.kozyheat.com ALP-36-L...
