4.13 Vector Drawing Tools

Pencil Tool
- draws isolated segments of Tracklogs and creates Waypoints.
To create a segment of Tracklog, press the left button and drag the mouse to the new position. Release the left
button to create the segment. For further information, see
To create a Waypoint, see
Route Creation Tool
- draws isolated segments of Routes and creates Waypoints.
To create a Route segment, place the mouse arrow on a Waypoint or on the extremity of a Route, press the left
button and drag the mouse to other Waypoint or other extremity of Route. Release the left button to create the
Route segment.
A Route can be created only if in its extremities there is another Route or a Waypoint. See the topic
Editing and Deleting Routes.
To create a Waypoint, see
Handfree Drawing Tool
- draws freely Tracklogs with multiple points.
Press the left button of the mouse and draw freely the Tracklog, maintaining the left button pressed. To conclude
the Tracklog, release the left button. The number of points will be shown in the status bar at the bottom of the
screen.
Line Drawing Tool
- draws Tracklogs with multiple points with segments of lines.
Click on time with left button at the beginning point and drag the mouse to the new position. It is not necessary to
drag the mouse with the left button pressed.
Each click with the left button creates a new vertex of the Tracklog.
To conclude the Tracklog, click with the right button of the mouse.
Creating, Editing and Deleting
Creating, Editing and Deleting
Creating, Editing and Deleting
Waypoints.
Waypoints.
54
Tracklogs.
Creating,
