GPS TrackMaker Reference Manual page 14

Waypoints
The second group of data saved in text file is the Waypoint:
w, Notation, Name, Lat, Lon, Comments, date, time, altitude, dspl, icon, Rotation, Zoom
w: flag indicating that data is related to a Waypoint
Notation: Type of Notation
Name: 6-character string
Latitude: Variable size string in the notation specified in Options
Longitude: Variable size string in the notation specified in Options
Comments: 40 characters string
Date : date in MM/DD/YY that the Waypoint was created
Time : hour, minute, second that the Waypoint was created
Altitude : altitude in meters
Dspl: indicates the display of the Waypoint on screen:
0 – Symbol with name
1 – Symbol Only
2 – Symbol with comments
3 – Symbol with comments defined by User
Icon: internal code of the icon symbol, according to the Icon Table
Rotation : angle of text rotation in degrees x 10
Zoom Level : Maximum zoom which the Waypoint appears on screen. See
Tracklogs
After Waypoints, the Tracklogs are saved as follows:
t, Notation, Latitude, Longitude, date, time,altitude, flag
t: flag indicating that the data is related to a Tracklog
Notation: Type of Notation
Latitude: Variable size string in the notation specified
Longitude: Variable size string in the notation specified
Date: date in Month / Day / Year format
Time: time in Hour: Minutes: Seconds format
Altitude : altitude in meters
flag: Boolean number that identifies the Tracklog:
0 – means a continuation for the same Tracklog
1 – means the beginning of a new Tracklog
Name, Colors and Styles of Tracklogs
After saving Track points, the names, colors and styles of Tracks will be registered. Styles indicate how Tracklogs
will be shown in the screen of the program.
n, Track Name, Track Color, Track Style, Zoom
Routes
The Routes are saved in the following format:
rn, Route Number, Route Name
rn: flag indicating the beginning of a new Route
Route Number: Integer value of the Route Number
as defined in Options menu
as defined in Options menu
Zoom Table
14
.
