GPS TrackMaker Reference Manual page 20

Export Parameters
Create Layers: Whenever possible, this option should be selected to create five different layers that will facilitate
a better visualization in AutoCAD®. The Created layers will have the following names:
• Comments: Layer of Waypoint comments
• Names: Layer of the Waypoint names
Routes: Layer of the Routes
•
Tracklogs: Layer of the Tracklogs
•
• Waypoints: Layer of circles and indicative points of Waypoint icons
Colors: Creates the export with the same colors indicated in GPS TrackMaker®. If this option is not selected,
the data will be exported in black or white color, depending on the background color defined in AutoCAD®.
Text Height
Choose the maximum height of the text and of the icon from exported Waypoints, avoiding confusion when the
Zoom tool is used in AutoCAD® environment. The height is indicated in meters and it will be shown to scale, even
if the data is exported using geographic coordinates.
