GPS TrackMaker Reference Manual page 15

Route Name: String up to 30 characters
r , Notation, Waypoint Name , Latitude , Longitude , Comments , dspl , icon
r : flag indicating that the data is related to a Route
Notation: Type of
Notation
Waypoint Name: 6-character string
Latitude : Variable size string in the notation specified in Options of the latitude of the Route's Waypoint
Longitude : Variable size string in the notation specified in Options , reflecting the longitude of the Waypoint of the
Route
Comments : 40-character string of the comment of Waypoint of the Route
dspl : byte that indicates the Waypoint's display scheme on the screen of the GPS:
0 – Symbol with name
1 – Symbol only
2 – Symbol with comments
3 – Symbol with comments defined by User
Icon : internal code of the icon symbol, according to the
Images
Background images can be saved in TXT files, if Save Images in TXT file option is selected under Options ->
Images in the Tools menu.
The images are saved with the following attributes:
i , Notation, Latitude1 , Longitude1, Latitude2 , Longitude2, Path, Text
i : flag indicating that the data is related to a Image
Notation: Type of
Notation
Latitude1/longitude1: Coordinates of upper-left corner of the image
Latitude2/longitude2: Coordinates of lower-right corner of the image
Path : Complete path of the image
Text : Text of the image
Zoom Table
Zoom values are defined between 0 to 12 and indicate the maximum scale which the element appears on screen.
12 = 100m : Street
11 = 300m : Avenue
10 = 500m : Highway
09 = 2Km : Neighborhood
Important Notes
Text files saved by GPS TrackMaker® do not indicate data related to background and grid colors, Waypoint text
characteristics, text defined by User or coordinate characteristics indicated on the grid. This data is stored only in
GTM and GTZ (GTM compressed) files.
defined in Options menu
defined in Options menu
08 = 10Km :
07 = 30Km :
06 = 70Km :
05 = 100Km :
Icon Table
Urban Area
Metropolitan Area
City Small
City Medium
15
04 = 250Km : City Large
03 = 500Km : State Medium
02 = 1000Km : State Large
01 = 2000Km : Country
00 = Permanent
