Summary of Contents for Microsens MS453510

  • Page 1: User Manual

    4 10/100/1000TX + 1 Mini-GBIC Switch User Manual MS453510...
  • Page 2: Ce Mark Warning

    CE Mark Warning This is a Class-A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
  • Page 3: Table Of Contents

    Content INTRODUCTION ................1 Features ....................... 1 Package Contents ....................2 HARDWARE DESCRIPTION ............3 Physical dimension ....................3 Front Panel ......................3 Rear Panel ......................3 LED Indicators ...................... 4 Desktop Installation ....................6 Attaching Rubber Feet .................. 6 Power On ......................
  • Page 5: Introduction

    Introduction The 4 10/100/1000TX + 1 Mini-GBIC Switch is a multi-port Switch that can be used to build high-performance switched workgroup networks. The Switch is targeted at workgroup or department. The 4 10/100/1000TX + 1 Mini-GBIC Switch features a “store-and-forward “...
  • Page 6: Package Contents

    Package Contents Unpack the contents of the 4 10/100/1000TX + 1 Mini-GBIC Switch and verify them against the checklist below:  4 10/100/1000TX + 1 Mini-GBIC Switch  DC Power Cord  Four Rubber Pads  User Manual 4 10/100/1000TX + 1 Mini-GBIC Switch Four Rubber Pads DC Power Adapter User Manual...
  • Page 7: Hardware Description

    Hardware Description This section mainly describes the hardware of the 4 10/100/1000TX + 1 Mini-GBIC Switch, and gives a physical and functional overview on certain switch. Physical dimension The 4 10/100/1000TX + 1 Mini-GBIC Switch physical dimension is 165 x 100 x 32.5 mm (L x W x H).
  • Page 8: Led Indicators

    The Rear Panel of 4 10/100/1000TX + 1 Mini-GBIC Switch  RJ-45 Ports (Auto MDI/MDIX): 4x 10/100/1000 N-way auto-sensing for 10Base-T, 100Base-TX or 1000Base-T connections. In general, MDI means connecting to another Hub or Switch while MDIX means connecting to a workstation or PC. Therefore, Auto MDI/MDIX would allow connecting to another Switch or workstation without changing non-crossover or crossover cabling.
  • Page 9 The port is operation at the speed of Yellow 100Mbps. In 10Mbps mode or no device attached The port is well connected with the Green device. The port is in processing of receiving Blinks Green LNK /ACT or transmitting data. No device attached.
  • Page 10: Desktop Installation

    Desktop Installation Set the switch on a sufficiently large flat space with a power outlet nearby. The surface where you put the switch should be clean, smooth, level and sturdy. Make sure there is enough clearance around the switch to allow attachment of cables, power cord and allow air circulation.
  • Page 11: Network Application

    Network Application This section provides user a few samples of network topology in witch the switch is used. In general, the 4 10/100/1000TX + 1 Mini-GBIC Switch is designed as a segment switch. That is, with its address table (8000 MAC address) and high performance, it is ideal for interconnecting networking segments.
  • Page 12 Two 4 10/100/1000TX + 1 Mini-GBIC Switches with PCs, print server, and local server attached, are both connected to the core switch. All the devices in this network can communicate with each other through the 4 10/100/1000TX + 1 Mini-GBIC Switch. Connecting servers to the 4 10/100/1000TX + 1 Mini-GBIC Switch allows users accessing the data on server.
  • Page 13: Troubleshooting

    Troubleshooting This section is intended to help user to solve the most common problems on the4 10/100/1000TX + 1 Mini-GBIC Switch. Incorrect connections The switch port can auto detect straight or crossover cable when the switch link with other Ethernet device. For the RJ-45 connector should use correct UTP or STP cable, 10/100Mbps port use 2 pairs twisted cable and Gigabit 1000T port use 4 pairs twisted cable.
  • Page 14: Improper Network Topologies

    connections or 100 Ω Category 5 cable for 100Mbps connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet). Gigabit port should use Cat-5 or cat-5e cable for 1000Mbps connections. The length does not exceed 100 meters. ...
  • Page 15: Technical Specification

    Technical Specification This section provides the specifications of 4 10/100/1000TX + 1 Mini-GBIC Switch. IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet Standard IEEE 802.3ab 1000Base-T IEEE 802.3z Gigabit Fiber IEEE 802.3x Flow Control and Back-pressure Protocol CSMA/CD Technology Store-and-Forward switching architecture 14,880 pps for 10Mbps Transfer Rate...
  • Page 16 10BASE-T: 2-pair UTP/STP Cat. 3, 4, 5 cable EIA/TIA-568 100-ohm (100m) 100BASE-TX: 2-pair UTP/STP CAT. 5 cable Network Cable EIA/TIA-568 100-ohm (100m) Gigabit Copper: 4 pair UTP/STP CAT. 5 cable EIA/TIA 568 100-ohm (100M) Gigabit copper: 4 x RJ-45 with Auto-MDIX Connector MINI GBIC: 1 x MINI GBIC socket (3.3v) Back-plane...
  • Page 18: Appendix

    Appendix 10 /100BASE-TX Pin outs With10 /100BASE-TX cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data.  RJ-45 Pin Assignments Pin Number Assignment [NOTE] “+” and “-” signs represent the polarity of the wires that make up each wire pair.
  • Page 19: 10/100/1000Base-Tx Pin Outs

    Straight-through cable schematic Cross over cable schematic 10/100/1000Base-TX Pin outs The following figure shows the 10/100/1000 Ethernet RJ-45 pin outs.
  • Page 20: 10/100/1000Base-Tx Cable Schematic

    10/100/1000Base-TX Cable Schematic Straight through cables schematic Cross over cables schematic...
