Microsens MS450154PM-48 Configuration Manual

Installation-Switch 45x45
with Twisted Pair Uplink
Introduction
Future proof Concept
The MICROSENS fiber to the office concept with the intelligent combination of fiber and twisted
pair cabling offers a long term and future proof investment.
Easy Installation
Due to the tool-less snap-in mounting the installation of the switches is made very easy and fast.
With this most compact system available on the market, the compatibility to the most common
manufacturers of building installation systems is given.
Optional Version with Power-over-Ethernet (PoE)
With the implementation of the IEEE802.3af standard it is possible to supply end devices such as
IP-telephones, Access Points and cameras direct with electrical from the installation switch. The
switch is able to operate either as a power source (Power Source Equipment = PSE) or can be
supplied with power (Powered Device = PD) over the TP-uplink.
Comprehensive Management
The integrated management offers the complete configuration, monitoring and administration
of all devices in the network via a powerful software packet, the MICROSENS Device Manager.
Additional features such as VLANs, Data prioritisation (QoS) and Power-over-Ethernet can be
configured individually.
Using the firmware upgrade option it is possible to expand the functionality of the switch
without any hardware changes (e.g. authentication, SNMP, Telnet, etc.).
Features
•
Switch
Fan less Fast Ethernet 10/100 Mbps installation switch according IEEE802.3
Layer 2 non-blocking switch, wire speed forwarding, store-and-forward, ma. 1024 MAC
addresses, auto learning and aging, 1 MB RAM, Full Duplex Frame according IEEE802.3x
•
Installation
Simple installation due to snap-in (without screws) into cable trunks and sub floor boxes,
small dimensions
•
Power Supply
Integrated power supply 100-240 V AC, PoE Version with 48 V DC input (via external
power supply) for switch and Power-over-Ethernet, max. power consumption of the
switch 3.5 W (without PoE supply), PoE max. 60 W (4x 15 W per port)
Depending on the application the use of a power supply is complete unnecessary. The
switch is supplied with power direct via the PoE capable TP-uplink (Powered Device = PD)
•
Twisted-Pair Ports
5x 10/100Base-TX (RJ-45), auto negotiation for the detection of the speed 10/100 Mbps
and half or full duplex, auto crossover for the automatic configuration of the pinout
enabling implementation of homogeneous cabling
Full Power-over-Ethernet function according IEEE802.3af on all ports
•
Management
Integrated management agent, port based configuration via PC based Management Tool
for speed (10/100 Mbps), full/half duplex, auto negotiation, auto crossover and port
Power-over-Ethernet
Data prioritisation (Quality of Service): 4 priority levels, port based (hardware priority),
Tag based (IEEE 802.1p/Q VLAN-Tag), IP TOS-field (DiffServ. Codepoints)
•
Firmware Options
SNMP, Telnet, RADIUS authentication, web based management
