LifeShield home security system Setup Manual page 7

4
Change Preprogrammed Sensors
or Add Additional Sensors
If you would like to change any of your preprogrammed sensors you can.
Just follow the steps below.
TO CHANGE PREPROGRAmmED SENSORS
Press MENU on Console
A
Scroll to Security Setup on the screen, press SELECT
B
Enter master Code* (found in the front cover of this book)
C
Scroll to Sensors
D
Select sensor to be modified
E
Use menu to select and change sensor attributes
F
TO ADD ADDITIONAL SENSORS:
Remove the battery tab by squeezing and holding the metal spring clip where
A
the REMOVE tab folds around battery. The battery will spring upward. Carefully
remove the insulating tab from under the battery, then gently press the battery
back into the spring clip
For this step you will need your Console and Sensor: Using Console:
Press MENU
B
Scroll to Security Setup, press SELECT
C
Enter master Code* (found in the front cover of this book)
D
Scroll to Sensors, press SELECT
E
On <Add New>, press SELECT
F
Scroll to the type of Sensor (Open/Close), press SELECT
G
Wait 5 seconds before clipping the Sensor into the Bracket.
H
You will then have 30 seconds to complete the setup
Clip the Sensor into the Bracket. The Console will beep when the system
I
finds the Sensor. This may take a few seconds
*IF "NO GCS HEARD SENSORS" IS DISPLAYED, THE SENSOR IS TOO FAR
FROM THE CLOSEST CONSOLE, BASE, OR CELLULAR GATEWAY.
Press OK
J
Edit Sensor Name (Optional. You can change the name now or at a later time)
K
• To change the Sensor Name, press the DELETE key to remove the default name
• Using the keys on your Console keypad, type in the desired name
• Press OK when complete
L Sensor Placement: Scroll to Door or Window. Press OK
M Alarm Type: Scroll to Stay & Away, Away Only, or Convenience. Press OK
Testing your Sensor:
With system disarmed, test your Sensor by opening the door or window.
N
Correct setup will generate a chime sound. If you don't hear, a chime sound, see
troubleshooting in the User Manual
Adding additional Sensors:
Repeat steps A-N for additional Sensors
O
6
*Note: Wherever Master Code is shoWN P lease use your uNique Master Code FouNd iN the FroNt Cover oF this book
A
Menu
B
Ready To Arm
Thu 2/8 11:48a
PHNBK MENU CONNCT
Squeeze & Hold
Metal Clip
Scroll
Buttons
WEATHR ALERTS
C
6
