LifeShield home security system Setup Manual page 16

13
Add Smoke Sensor (if included)
INSTALL SmOKE SENSOR
Remove the Smoke Sensor and related components from the box and physically install the
A
device according to the manufacturer's printed instructions.
NOTE: It is important to follow the manufacturer's printed instructions regarding placement
of the device (location), installation (mounting) and battery activation (including removal of
the battery tab insulator paper) prior to moving on to the next step involving integration of
this device with your LifeShield System.
B Once the mounting bracket is secured to the ceiling, attach the Smoke Sensor into it.
ADD THE SmOKE SENSOR TO THE LIFESHIELD SYSTEm
On the Handset or Console, press MENU.
A
Scroll to Security Setup, press
B
SELECT and enter the master Code*
C
D
Scroll to Sensors, press SELECT.
Scroll to <Add New>, press SELECT.
E
F
Scroll to Smoke Sensor, press SELECT.
Following the instructions displayed on the LCD screen: Wait 5 seconds then detach the Smoke
G
Sensor from the mounting bracket ("Un-clip Sensor from bracket"). (You will have 30 seconds to
complete this step.)
When the Smoke Sensor has successfully been added you will hear 4 fast confirmation beeps from the
LifeShield system. If there are no confirmation beeps, check to make sure that the battery insulator tab
has been removed, re-attach the Smoke Sensor to the mounting bracket and repeat the steps above
Once the Smoke Sensor has been added to the LifeShield system:
Use the Edit feature to rename the device (if desired). (Press DELETE to erase text and the
H
keypad keys to type new ones).
I Press OK, then press BACK until the Main Menu is displayed.
J Re-attach the Smoke Sensor to the mounting bracket.
TEST THE SmOKE SENSOR
On the Handset or Console, press MENU.
A
Scroll to Utilities, press SELECT
B
Scroll to Test, press SELECT
C
D
Enter your master Code*
Select System Test
E
F
Press the SKIP soft key to skip the Siren Test
Press the OK soft key on next screen for Starting Comm Test
G
Scroll to the name of the Sensor that you would like to test, and press SELECT
H
On the Smoke Sensor, press the small Test button located on the front cover for at least 30 seconds
I
If the Smoke Sensor test is successful, the LCD screen will display "Sensor xxx Passed". If these
words do not appear, return to "Add the Smoke Sensor to the LifeShield System".
*Note: Wherever Master Code is shoWN P
15 lease use your uNique Master Code FouNd iN the FroNt Cover oF this book
