LifeShield home security system Setup Manual page 4

1A
Connect Base (Home Essential Kit)
A Put the Base near your Modem/Router
Remove the stand by sliding the Table
Stand downward from the main body of
B
the Base
Insert the battery, then replace the Table
Stand by sliding upward onto the main
C
body of the Base
Insert the power adapter, plug fully into the
jack on the back of the Base. Then plug the
D
power adapter into the wall outlet.
Connect the Ethernet Cable between an
E available port on your router and the back
of the Base
Continue to Step 2
F
OPTIONAL: IF YOU CONNECT A PHONE CORD FROM THE SYSTEM BASE TO A TELEPHONE WALL JACK, YOU'LL
HAVE A BACK-UP PATH FOR ALARM COMMUNICATIONS IF YOUR INTERNET CONNECTION ISN'T FUNCTIONING.
1B
Connect Cellular Gateway
(Home Essential Kit-Celluar Ready )
For ideal reception, put the Cellular Gateway near
A
an outside wall outlet on a high floor in your home
Remove the back cover of the Cellular Gateway
B
Plug the battery pack into the plug receptacle and
C
insert the battery into the battery compartment
Replace the back cover
D
E
Plug the Cellular Gateway into the lower electrical
outlet with the tab facing upward
Continue to Step 2
F
3
If you ordered the Home Essential Kit start here, then proceed to Step 2.
C
-
If you ordered the Home Essential - Cellular Ready Kit start here, then proceed to Step 2.
D
+
B
Table Stand
C
Battery
Pack
Base Back View
E
Ethernet Cable
Cellular Gateway E
Back View
B
(Optional)
Phone Cord
Modem/Router
