  • Page 1 Translation of the original operating instructions Translation of the original operating instructions Translation of the original operating instructions Grassland Mower Grassland Mower Grassland Mower Grassland Mower Grassland Mower 5300 5300 5300 5300 5300 - Honda Engine - Robin Engine 4238 Before commissioning the machine, read operating instructions and observe warnings and safety instructions.

  • Page 2: Amount Of Delivery

    Please state these data when order- Air filter ing spare parts to avoid wrong deliv- eries. Visual check Only use original agria spare parts! Specifications, figures and dimen- Clutch sions stated in these instructions are Mowing drive not binding. No claims can be derived from them.

  • Page 3: Designation Of Parts

    Designation of Parts Robin Engine Honda Engine 13 7 agria Grassland Mower 5300...
  • Page 4 6 Engine type no. 7 Starter handle 8 Cooling-air screen 9 Exhaust with exhaust guard 10 Spark plug, spark plug connector 11 Engine oil filler plug – control opening 12 Engine oil drain screw 13 Fuel tap agria Grassland Mower 5300...

  • Page 5: Table Of Contents

    4. Commissioning and Operation Fig. C and D ......50 Commissioning the Machine ..27 Starting the Engine ......28 Shutting off the Engine ....29 Mowing ........... 30 Danger Zone ........31 Mowing on Slopes ......31 agria Grassland Mower 5300...

  • Page 6: Recommendations Lubricants, Anti-Corrosive Agents

    (do not apply on painted covers). You Maintenance and Repair: can brush or spray the oil. Anti-corrosive agents are environmen- The trained mechanics of your agria tally friendly and degrade fast. workshop expertly carry out any main- tenance and repair work.

  • Page 7: Instructions For Unpacking And Assembly

    0 and lock it to disen- gage the wheel drive. This is to push the undriven ma- chine. Pull the machine rear- wards to remove it from the box. Attach the cutter bar (5), Carry out the start-up procedure agria Grassland Mower 5300...

  • Page 8: Safety Instructions

    Any unauthorized changes to the mower Careful with rotating tools – keep at a render manufacturer liability null and safe distance! void. agria Grassland Mower 5300...
  • Page 9 Never adjust the operating handles dur- ing work – danger! For operation in enclosed areas, ensure that a safety distance is kept to enclo- sures to prevent damage to tools. agria Grassland Mower 5300...
  • Page 10 Do not transport the dismounted cutter Secure grassland mower against unau- bar without knife guards. thorized use. If mower is equipped with ignition key, remove the key. For all other versions, remove spark plug connector. agria Grassland Mower 5300...
  • Page 11 Snow Clearing Only use original agria spare parts. All Ensure snow dozer is mounted cor- other commercial spare parts must cor- rectly! Wear slip-proof shoes.
  • Page 12 Read and observe enclosed instruc- tions. Before you dispose of opened and seemingly empty pressurised tins (e.g. of assist-starting liquids) make sure they are completely empty. Empty them in agria Grassland Mower 5300...

  • Page 13: Safety Instructions ...... 8

    With engine running, keep at a safe dis- tance from cutting tools. Signs When working with the ma- chine, wear individual protec- tive ear plugs. Wear protective gloves. Wear solid shoes. agria Grassland Mower 5300...

  • Page 14: Specifications

    Clutch: Grassland Mower V-belt clutch with idler pulleys between engine and transmission Friction clutch for reverse Only use original agria V-belts! (see Machine Dimensions: list of wear parts p47) Transmission: ....Worm gear with engageable wheel-drive Transmission oil SAE 90-API GL5 Filling quantity ....

  • Page 15: Engine

    1-cylinder, 4-stroke petrol ohv engine octane number at least 91 RON Manufacturer: ......Honda (also E10) refer to fuel recommendations Mower type: 5300 441 5300 531 Engine type: GX 160 GX 200 Air filter: ....Dry element filter K1 QPU...
  • Page 16 (with oil level at “max“”= upper level screened according to VDE 0879 mark) Valve lash (engine cold): Intake: ....0.15 mm ±- 0.02 mm Outlet: ....0.20 mm ± 0.02 mm Starter: Soft-pull recoil starter with mechanical decompression facility agria Grassland Mower 5300...

  • Page 17: Devices And Operating Elements Engine

    Universal SC cutter bar 105 cm (agria Item no. 5347 751) Idle running speed 122 cm (agria Item no. 5347 661) Always ensure that idling-speed is ad- Municipal cutter bar justed correcty.

  • Page 18: Safety Circuit

    (C/5) and lock with pawl (C/6). Operating position: To operate the machine press safety circuit lever (C/4). Do not fasten safety circuit lever. Release the safety circuit lever in an emergency situation, the lever automatically goes to STOP position. agria Grassland Mower 5300...

  • Page 19: Travelling Drive

    Watch for the correct clutch play (X) to avoid clutch slipping away during opera- tion. Note: Always park mower with hand clutch lever pulled (“0” – pawl locked), otherwise clutch problems may arise due to deformation of V-belt. agria Grassland Mower 5300...

  • Page 20: Mowing Drive

    Then engage wheel-drive. Mowing Drive The mowing drive is crank driven. The mowing drive is engaged and dis- engaged via the gear lever (C/7). Only engage mowing drive when the machine is decoupled (in neutral). agria Grassland Mower 5300...

  • Page 21: Steering Handle

    (3) locks into long hole of location in steering bar joint). Steering handle side adjustment Loosen knob screw (1) until all notches are free. Swivel the steering handle to the de- sired position and fit into proper toothing. Re-tighten knob screw. agria Grassland Mower 5300...

  • Page 22: Drive-Wheels

    Let detent spring engage in a ring groove again (fig. K and L). Brush Bio-lubricating grease onto both ends of wheel-shaft (small diam- eter of wheel-shaft). For dismounting drive-wheels, proceed accordingly but in reverse order. agria Grassland Mower 5300...
  • Page 23 (fig. L). Drive with differential effect: En- gage one drive-wheel into inner ring groove (fig. K), engage the second drive- wheel into outer ring groove (fig. L) – neutral. agria Grassland Mower 5300...
  • Page 24 Cage Drive-Wheels Dismount drive-wheels. Mount cage drive-wheels onto wheel- shaft (as described in “Mounting Drive- Wheels”). Rigid drive, neutral, drive with differential effect are also avail- able with twin and cage drive-wheels mounted. agria Grassland Mower 5300...

  • Page 25: Cutter Bar

    Universal SC cutter bar Insert carrier pin (2) into location bor- 105 cm (agria Item no. 5347 651) ing (3) of mowing drive housing and 122 cm (agria Item no. 5347 661) push in to a stop.
  • Page 26 For a higher cut, 2 height-ad- justable running bases can be mounted onto the cutter bar. (Optional pair of running bases = agria Item no. 713 22) On cutter bar version S, re-fit the glid- ing skid in such a way that the convex face points upwards (see fig.

  • Page 27: Commissioning And Operation Commissioning The Machine

    Note: For reasons of transport, the machine is not filled with engine oil! Before you operate the engine the first time, fill in engine oil Please observe the references of the engine operating instructions! agria Grassland Mower 5300...

  • Page 28: Starting The Engine

    Caution with hot engine parts! The exhaust and other engine parts become very hot, if the engine runs and immediately after turning off. Hold for sufficient distance from hot surfaces and keep children away from the running engine. agria Grassland Mower 5300...

  • Page 29: Shutting Off The Engine

    This is to ensure the carburetor is empty and to avoid resin deposits. speed control lever also serves to shut off the engine in an emer- gency situation. If necessary, move this lever to po- sition “STOP” to shut off the engine. agria Grassland Mower 5300...

  • Page 30: Mowing

    15 - 30 operating minutes and than every 4 operating hours (particularly of the cutter bar carrier, the knife driver and the mower mounted flange). agria Grassland Mower 5300...

  • Page 31: Danger Zone

    Starting the engine on slopes Keep the mowing drive and the wheel-drive in engaged mode; brak- ing effect. Move the hand clutch lever and emergency-off-switch into "Start" po- sition. Start the engine. agria Grassland Mower 5300...

  • Page 32: Maintenance

    Use a funnel or a similar de- vice to fill the oil reservoir. Replace the oil filler plug (2) and tighten it. Only change oil while the engine is still warm, but not hot – dan- ger of burns! agria Grassland Mower 5300...

  • Page 33: Cooling System

    Check each time before you take up operation. Speed Actuating Devices Devices for actuating engine speed must be adjusted correctly to start, operate and switch off the engine at correct speed rates. - Service All other maintenance of the engine agria Grassland Mower 5300...

  • Page 34: Machine

    Constantly check wheel-shaft for wound-on grass, remove by dismounting drive- wheels, if necessary. Lubricate with Bio-lubricating grease wheel-shaft ends (small shaft diameter) each time before you mount drive-wheels, once a year, and after cleaning with air-compressed water jets. agria Grassland Mower 5300...

  • Page 35: Mowing Attachment

    Lubricate lubrication nipple (3) of inter- When exchanging attachment locking bolt with Bio-lubricating grease bolts on knife driver, only use once a year and after each cleaning original agria bolts. Otherwise knives with air-compressed water jets. may break. Cleaning After each mowing, clean cutter bar thoroughly with water.

  • Page 36: Universal-S Cutter Bar

    First tighten the attachment bolts (e) sary. and then the clamping screws (c) very well (70 Nm) while you simultaneously press the knife holders (h) in the direc- tion indicated by the arrow (f) using a long ring spanner. agria Grassland Mower 5300...

  • Page 37: Municipal Cutter Bar

    Municipal Cutter Bar 1 Cutter bar blade Pressure 2 Pin rest 3 Pin sleeve Spring balance 4 Driver pin 5 Cutter bar back 7 Attachment bolt 8 Set screw 9 Bearing part 10 Clamping sleeve 11 Lubrication nipple agria Grassland Mower 5300...

  • Page 38: Re-Grinding Mowing Knives

    15,000 to 20,000 rpm with a pot-shaped grinding pin of 25 mm in diameter and approx. 35 mm in length or a special grinding tool. Bottom knife ESM universal- municipal-cutter bar Top knife Wrong grinding Correct grinding agria Grassland Mower 5300...

  • Page 39: Safety Circuit

    Hand lever for clutch: X = 2.5–4 mm, the basic setting is adjusted in neutral position. In neu- tral, the gap between rubber pulley “II” and pulley “I” must be 2–3 mm (see “Adjusting V-Belt Tension”). agria Grassland Mower 5300...

  • Page 40: Adjusting V-Belt Tension

    Mount pulley and belt guard (D/8). For this purpose, the clutch lever must be in position “forward”. Do not use commercial V-belts. Only use original agria V-belts! Only operate the machine with all protective devices mounted and adjusted to provide protection.

  • Page 41: General Maintenance

    Engine Clean engine only with a cloth. Avoid spray- ing with water jets, as water might penetrate into ignition and fuel system and cause mal- functions. agria Grassland Mower 5300...

  • Page 42: Storage

    This closes the intake and g) Protect machine outlet valves to improve the engine’s pro- tection from internal corrosion. with cloth or a simi- lar cover. Crank the engine slowly at 2–3 week intervals (spark plug connector is re- moved). agria Grassland Mower 5300...
  • Page 43 Grassland Mower 5300...

  • Page 44: Troubleshooting

    6. Troubleshooting Observe safety instructions! Have all serious malfunctions on the ma- chine or engine repaired by your agria workshop. They have the proper tools. Improper repairs can only add to the damage. Problem Possible cause Possible solution Page Engine...
  • Page 45 - Top knife protrudes too far Adjust knife guides and wear plates 35 - 37 bottom knife over bottom knife work into blades of top knife = For this purpose contact your agria workshop. BM = Engine operating instructions agria Grassland Mower 5300...

  • Page 46: Electrical Wiring, Lubrication Chart

    5 Switch in safety circuit lever 6 Switch in clutch lever bl = blue br = brown Lubrication Chart Engine oil (page 32) Transmission oil (page 34) Mowing knife (page 35) Cutter bar drive (page 35) Lever bearing (page 41) agria Grassland Mower 5300...

  • Page 47: Varnishes, Wear Parts

    Gasket for housing cap (worm gear) 481 75 V-belt for clutch 481 74 V-belt for reverse drive Note: Only use original agria V-belts! Honda engine 761 99 Air filter element set 759 99 Spark plug NGK BPR6 ES; Bosch WR7DC...

  • Page 48: Inspection And Maintenance Chart

    = Each time before you take up operation = After each cleaning BM = see engine operating instructions = Checks and maintenance to be executed by operator = Maintenance to be executed by professional workshop = after 2 years agria Grassland Mower 5300...
  • Page 49 5 Location holes for guard carrier 6 Driving pulley (on crankshaft) 7 Belt guide plate 8 Pulley and belt guard 9 Spring washer 10 Counternut 11 Rubber pulley for reverse 12 Drive belt for reverse 13 Driving pulley (on gearshaft ) agria Grassland Mower 5300...
