2. Loading Supplies

2.1 Adding Paper/Labels

The printer can print text, bar codes and graphics on thermal receipt paper. See "Supply
Specifications" for the width, thickness requirements and approved vendors.
Follow these steps to load printer paper.
Open the paper door by pressing the Paper Door Unlock Button on the top cover as indicated
in Figure 5.
The door will open slightly; open the rest of the way as shown.
Note: Paper Door Release button must be depressed when opening and closing paper door
Place the paper supply roll into the paper supply well. Make sure the paper supply unwinds
from the bottom as shown in Figure 6.
FIGURE 6: INSTALLING PAPER
S4000T User's Guide
FIGURE 5: OPENING THE PRINTER
Rev 1.2
FIGURE 7: CLOSING PRINTER
11
