3.7.5 Magnetic Card Reader Control Commands (When MCR is installed)
Command String
ESC - 'M' - 'nnm' – Cr
ESC - 'C'
3.7.6 Smart Card Reader Control Commands (when SCR is installed)
Command String
ESC - 'M' - 'nn' - '7'- Cr

3.7.7 Graphic Logo and Bar Code Commands

Esc – D – L <CR> or <LF>
ESC – 'L' – 'G' – n <CR> or <LF>
Esc – 'L'- 'G'- 0xFF <CR> or <LF>
ESC – 'L' – 'g' – n
ESC – 'z' – n1 – n2 – L – [data] <CR>
ESC – 'Z' – n1 – n2 – L – [data] <CR>
ESC – 'Q' – 'J' – n
ESC – 'Q' – 'Q' – n
ESC – 'Q' – 'F' – m
ESC – 'Q' – 'B' – m

3.7.8 Printer Supervisory and Control Commands

^V
^B
ESC – 'M' – '000' - cr
ESC – 'M' – 'nn0' - cr
ESC – 'C'
ESC – 'P' – '( '
ESC – 'P' – ')'
S4000T User's Guide
Printer Action
Select MCR with (nn) auto timeout Where nn="00" to "99"
m=1: Reads track 1 only
m=2: Reads track 2 only
m=3: Reads track 3 only
m=4: Reads track 1 & 2
m=5: Reads track 2 & 3
m=6: Reads track 1, 2 & 3
Cancel MCR read process
Printer Action
Select SCR in direct mode with Serial RS232.
(nn) is the auto timeout of the SCR.
Command String
Command String
Printer Action
Enable download mode
Specify logo location
End Logo Download
Print stored logo image
Print Bar Code without visible text
Print Bar Code with visible text
Reverse Dot Feed
Set Out of Paper Sensitivity
Set Forward Black Mark Seek
Reverse Black Mark Seek
Printer Action
Buffer, power timer, Print Head & battery
status
Buffer status
Disable the power down timer
Sets the power down timer to nn seconds
Reset Auto power down to 20 seconds
Firmware version query
Hardware model query
Rev 1.2 21
