Pentium mmx processor-based panel pc with 15" lcd flat panel display.
Hide thumbs Also See for PPC-150 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
PPC-150
®
Pentium
MMX processor-based
panel PC with 15" LCD flat panel
display.
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-150 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech PPC-150 Series

Summary of Contents for Advantech PPC-150 Series

  • Page 1 PPC-150 ® Pentium MMX processor-based panel PC with 15" LCD flat panel display. User’s Manual...

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted, 2000, by Advantech Co. Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to alter the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech.
  • Page 3 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.

  • Page 4: Packing List

    Packing List Before installing your panel PC, ensure that the following materials have been received: • PPC-150 series panel PC • User's manual • Accessories for PPC-150 - Y-shaped adapter for PS/2 mouse and AT keyboard - Power cord (1.8 m) - USA type (other types are available on request) - Floppy disk with CD-ROM drive driver - "Drivers and Utilities"...
  • Page 5 Additional Information and Assistance 1. Visit the Advantech Web sites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.

  • Page 6: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 7 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.

  • Page 8: Table Of Contents

    Table of Contents Chapter 1 General Information...........1 1.1 Introduction ..............2 1.2 How to Use This Manual ..........4 1.3 Specifications ..............6 1.4 Dimensions ..............10 Chapter 2 System Setup...........11 2.1 A Quick Tour of the Panel PC ........12 2.2 Preparing For First-time Use........15 2.3 Installation Procedures ..........16 2.3.1 Connecting the AC power cord ..........
  • Page 9 3.9 VGA Port ..............34 3.10 Game Port ..............34 3.11 USB Ports ..............34 3.12 Audio Interface ............35 3.13 Ethernet ..............35 3.14 Adjusting the LCD Contrast and Brightness ....35 3.15 Touchscreen (Optional) ..........36 Chapter 4 Hardware Installation and Upgrading.....37 4.1 Overview of Hardware Installation and Upgrading ..38 4.2 Disassembling the Panel PC ........39 4.3 Installing the 2.5"...
  • Page 10 5.4 VGA Interface .............64 5.4.1 LCD panel power setting (JP6) ..........64 5.4.2 Panel type select (JP9) ............65 5.5 Watchdog Timer Configuration ........67 5.5.1 Watchdog activity selection (JP15) ........67 Chapter 6 PCI Bus Ethernet Interface......69 6.1 Introduction ..............70 6.2 Installation of Ethernet Driver ........70 6.2.1 Installation for MS-DOS &...
  • Page 11 9.2 CMOS Setup Utility ...........104 9.3 Standard CMOS Setup ..........105 9.3.1 Hard Disk Configurations ........... 106 9.4 BIOS Features Setup ..........107 9.5 Chipset Features Setup ..........110 9.6 Power Management Setup ........111 9.7 PNP/PCI Configuration Setup ........115 9.8 Load BIOS Defaults ..........117 9.9 Load Setup Defaults ..........117 9.10 Integrated Peripherals ..........118 9.11 Password Setting ............121...
  • Page 12 Programming the Watchdog Timer ......148 Chapter C Full Disassembly Procedures.......151 Chapter D Pin Assignments..........159 IR Connector (J1) (*Reserved) .........160 Flat Panel Display Connector (J2) ......161 Flat Panel Display Connector (J3) ......162 Internal COM4 Connector (J4) ........162 Touchscreen Power Connector (J5) ......162 Sandisk SSD Connector (J6) ........164 EIDE Hard Disk Drive Connector (J7) .......164 Floppy Drive Connector (J8) ........166...
  • Page 13 Table 5-11: COM2 RS-232/422/485 setting (JP3, JP4) ......62 Table 5-12: COM2 RS-232/422/485 setting (JP5) ........62 Table 5-13: PPC-150 serial port default settings ........63 Table 5-14: COM4/RI pin setting (JP2) ........... 63 Table 5-15: COM3/RI pin setting (JP1) ........... 63 Table 5-16: Panel VCC setting (JP6) ............
  • Page 14 Table D-20: COM2..................175 Figures Figure 1-1:The panel PC in perspective............ 3 Figure 1-2: How to read the PPC-150 manual .......... 5 Figure 2-1: Front view of the panel PC ........... 12 Figure 2-2: Left side view of the panel PC ..........13 Figure 2-3: Rear view of the panel PC ............
  • Page 15 Figure C-2: Steps 5 - 6 ................. 155 Figure C-3: Steps 7 - 12 ............... 157 Figure E-1: Cutout dimensions of the PPC-150 ........178 Figure E-2: Panel mounting ..............179 Figure E-3: Dimensions of panel mounting holes ........180 Figure E-4: Desktop stand mounting ............

  • Page 17: Chapter 1 General Information

    General Information This chapter gives background information on the PPC-150 panel PC. • Introduction • How to Use This Manual • Specifications...

  • Page 18: Introduction

    PCMCIA expansion sockets, the PPC-150 is as compact and user-friendly as a notebook computer. Unlike notebook computers, the PPC-150 is more durable and versatile in all applications. The panel PC can be placed on a desktop to replace the traditional desktop computer. In addition, its "fit anywhere"...

  • Page 19: Figure 1-1:The Panel Pc In Perspective

    Touchscreen CRT Monitor Network modem Speakers Printer Keyboard Joystick Mouse Figure 1-1:The panel PC in perspective Chapter 1 General Information...

  • Page 20: How To Use This Manual

    Chapter 1 (this chapter) outlines the organization of this User's Manual, provides a complete specification description of the PPC-150, and summariz- es its main features. Chapter 2 provides step-by-step instructions to help you set up and begin using the panel PC as quickly as possible.

  • Page 21: Figure 1-2: How To Read The Ppc-150 Manual

    PC. A suggested guideline for reading this manual is shown below: Systems Integrators: Appendices A - E Systems Upgrades: Chapter 4-5 Commercial Users: Chapters 1-3, 6-9, 10 (optional) Figure 1-2: How to read the PPC-150 manual Chapter 1 General Information...

  • Page 22: Specifications

    IDE devices. Each channel supports PIO modes 0 ~ 4, DMA mode 0 ~ 2, and Ultra DMA 33 simultaneously. The secondary connector is designated for the CD-ROM drive. BIOS supports IDE CD-ROM boot-up. PPC-150 User's Manual...

  • Page 23: Audio Function

    • Floppy disk drive: Supports up to two FDDs (720K/1.44MB). One built- in FDD included inside FDD housing • Parallel port: One parallel port, supports SPP/EPP/ECP parallel mode. BIOS configurable to LPT1, LPT2, LPT3 or disabled • Serial ports: Four serial ports with three RS-232 ports (COM1, 3, and 4), one RS-232/422/485 port (COM2).

  • Page 24: Pci Bus Ethernet Interface

    Windows NT4.0 Durability (touches in a 30 million 20 million 50 million lifetime) Note: The panel PC with the optionally installed touchscreen will share COM4. Once the touchscreen is installed, COM4 cannot be used for other purposes. PPC-150 User's Manual...

  • Page 25: Optional Modules

    Optional modules ® • CPU: Intel Pentium 75 ~ 233 MHz with MMX, P55C/P54C, AMD K5, K6, K6-2 Cyrix M1, M2 • Memory: 16/32/64/128 MB SDRAM • HDD: 2.5" HDD • Touchscreen: Analog resistive,capacitive or Surface Acoustic Wave • CD-ROM drive: Compact 24X CD-ROM or above •...

  • Page 26: Dimensions

    1.4 Dimensions Figure1-3: Dimensions of the PPC-150 PPC-150 User's Manual...

  • Page 27: Chapter 2 System Setup

    System Setup • A Quick Tour of the Panel PC • Preparing for First-time Usage • Running the Setup Program • Installing the System Software • Installing the Drivers...

  • Page 28: A Quick Tour Of The Panel Pc

    When you place the panel PC upright on the desktop, its front panel appears as shown in Figure 2-1. Figure 2-1: Front view of the panel PC PPC-150 User's Manual...

  • Page 29: Figure 2-2: Left Side View Of The Panel Pc

    When you look at the left side of the panel PC, you will see the floppy disk drive, CD-ROM drive and PCMCIA expansion sockets, as shown in Fig. 2-2. Compact CD-ROM drive FDD eject button CD-ROM drive activity light FDD slot CD-ROM eject button PCMCIA socket FDD activity light...

  • Page 30: Figure 2-3: Rear View Of The Panel Pc

    USB ports Ethernet jack Parallel port Brightness adjust knob Serial ports Contrast adjust knob Line out jack VGA port Line in jack Game port Microphone in jack Figure 2-3: Rear view of the panel PC PPC-150 User's Manual...

  • Page 31: Preparing For First-Time Use

    Figure 2-4 shows the I/O section and power switch of the panel PC. Main power switch AC inlet Figure 2-4: Tilted rear view of the panel PC 2.2 Preparing For First-time Use Before you start to set up the panel PC system, you should have at least the following items ready: •...

  • Page 32: Installation Procedures

    1. Connect the female end of the power cord to the AC inlet of the panel PC. (See Fig. 2-5.) 2. Connect the 3-pin male plug of the power cord to an electrical outlet. AC inlet Electrical outlet Power cord Figure 2-5: Connecting the power cord PPC-150 User's Manual...

  • Page 33: Installing The Dc Power Insulator With Hood

    2.3.2 Installing the DC power insulator with hood The panel PC can also be powered by DC electrical outlet (19 V ~ 30 V typical 24 V or 10.5 V ~ 16 V , typical 12 V , which depends on the power type).
  • Page 34 2 connects to the frame ground ( G ), and pin 3 should be plugged into the negative DC power input ( - ). Bottom tray STEP 3 : Mount the front part of the male insulator onto the bottom tray. PPC-150 User's Manual...
  • Page 35 Metal plate STEP 4: Use the metal plate and the two screws to secure the cables to the bottom tray. Please refer to the illustration above. Upper cap STEP 5 Attach the upper cap to the bottom tray and secure it with the screws.
  • Page 36 STEP 6 Now that you have completed the assembly of the male insulator, plug it into the female insulator. PPC-150 User's Manual...

  • Page 37: Connecting The Keyboard And Mouse

    2.3.3 Connecting the keyboard and mouse 1. Connect the Y-shaped adapter to the PS/2 mouse and keyboard port on the I/O section of the panel PC. (See Fig. 2-6.) 2. Connect the PS/2 mouse and keyboard to the Y-shaped adapter. (See Fig. 2-6.) If you use a serial mouse and your panel PC has a touchscreen, you can connect the mouse to any COM port except COM4.

  • Page 38: Running The Bios Setup Program

    The BIOS of the panel PC supports system boot-up directly from the CD-ROM drive. You may also insert your system installation CD-ROM into the CD-ROM drive. (See Fig. 3-2.) Refer to Chapter 9 - BIOS Setup if you wish to change the BIOS settings. PPC-150 User's Manual...

  • Page 39: Installing The Drivers

    Power on your panel PC or reset the system by pressing the "Ctrl"+"Alt"+"Del" keys simultaneously. The panel PC will automatically load the operating system from the diskette or CD-ROM. If you are presented with the opening screen of a setup or installation program, follow the instructions on screen.
  • Page 40 These files are a very useful supplement to the information in this manual. Note: The drivers and utilities used for the PPC-150 panel PCs are subject to change without notice. If in doubt, check Advantech's web site or contact our application engineers for the latest information regarding drivers and utlities.

  • Page 41: Chapter 3 Using The Panel Pc

    Using the Panel PC • Floppy Drive • CD-ROM Drive • PCMCIA Sockets • PS/2 Mouse and Keyboard • Audio Interface • PCI/ISA Bus Expansion • Parallel Port • Serial COM Ports • VGA Port • Game Port • USB Ports •...

  • Page 42: Introduction

    To eject a diskette, first ensure that the drive activity light is off, and then press the eject button on the drive. When the diskette pops out of the drive, remove it and store it properly. Floppy Disk Drive Floppy Disk Figure 3-1: Inserting and ejecting a floppy diskette PPC-150 User's Manual...

  • Page 43: Cd-Rom Drive

    3.3 CD-ROM Drive To insert a CD-ROM disc, press the eject button of the CD-ROM drive. The yellow activity light will flash and the front panel will come out a short distance. Using your fingertips, hold the top and bottom of the front panel and pull it outward to the very end.

  • Page 44: Pcmcia

    Then press the appropriate eject button on the socket. When the card pops out of the socket, remove it and store it properly. PCMCIA socket PCMCIA card Eject Button Figure 3-3: Inserting and ejecting a PCMCIA card PPC-150 User's Manual...

  • Page 45: Figure 3-4: Using The I/O Interface

    PS/2 keyboard mouse Network Printer Figure 3-4: Using the I/O interface (upper level ports excluding COM ports) Chapter 3 Using the Panel PC...

  • Page 46: Figure 3-5: Using The I/O Interface (Lower Level Ports And Com Ports)

    CD-ROM Serial Headphones Microphone Joystick player monitor mouse Figure 3-5: Using the I/O interface (lower level ports and COM ports) PPC-150 User's Manual...

  • Page 47: Ps/2 Mouse And Keyboard

    3.5 PS/2 Mouse and Keyboard If you wish to use a full-size desktop keyboard and PS/2 mouse with your panel PC, follow these instructions: 1. Be sure the panel PC is turned off. 2. Connect the Y-shaped adapter to the PS/2 mouse and keyboard port on the rear bottom side of the rear cover.

  • Page 48: Figure 3-6: Pci/Isa Bus Expansion

    PCI/ISA expansion slot cover PCI/ISA bus card Metal plate Figure 3-6: PCI/ISA bus expansion PPC-150 User's Manual...

  • Page 49: Parallel Port

    3.7 Parallel Port The panel PC supports the latest EPP and ECP parallel port protocols for improved performance and versatility with compatible printers or other devices. To connect the panel PC to a printer or other devices: 1. Be sure both the panel PC and the printer/devices are turned off. 2.

  • Page 50: Vga Port

    USB ports located on the rear side of the system unit. 1. Connect the external device to the system. (See Fig. 3-4.) 2. The USB ports support hot plug-in connection. You should install the device driver before you use the device. PPC-150 User's Manual...

  • Page 51: Audio Interface

    5. Run the Ethernet driver to connect up to the network. 3.14 Adjusting the LCD Contrast and Brightness The contrast control knob does not function because the PPC-150 includes the TFT LCD display. Only panel PCs with DSTN LCD displays have this function.

  • Page 52: Touchscreen (Optional)

    CD-ROM disc inside the accessory box. The touchscreen manual can also be found on this disc. Read Chapter 10 of this manual carefully before you install the driver. PPC-150 User's Manual...

  • Page 53: Chapter 4 Hardware Installation And Upgrading

    Hardware Installation and Upgrading • Overview of Hardware Installation and Upgrading • Disassembling the Panel PC • Installing the 2.5" Hard Disk Drive (HDD) • Installing the Central Processing Unit (CPU) • Installing the SDRAM Memory Module • Installing the Floppy Disk Drive (FDD) •...

  • Page 54: Overview Of Hardware Installation And Upgrading

    Do not remove the rear cover until you have verified that no power is flowing within the panel PC. Power must be switched off and the power cord must be unplugged. Every time you service the panel PC, you should be aware of this. PPC-150 User's Manual...

  • Page 55: Disassembling The Panel Pc

    4.2 Disassembling the Panel PC The following are standard procedures for disassembling the panel PC before you upgrade your system. All procedures are illustrated in Fig. 4-1. 1. Unscrew the seven screws that secure the rear cover, then remove the cover.

  • Page 56: Figure 4-1: Disassembling The Rear Panel Of The Panel Pc

    Rear panel CPU cover PCI/ISA expansion PCB Side panel Figure 4-1: Disassembling the rear panel of the panel PC PPC-150 User's Manual...

  • Page 57: Installing The 2.5" Hard Disk Drive (Hdd)

    4.3 Installing the 2.5" Hard Disk Drive (HDD) You can attach one enhanced Integrated Device Electronics (IDE) hard disk drive to the panel PC's internal controller which uses a PCI local-bus interface. The advanced IDE controller supports faster data transfer and allows the IDE hard drive to exceed 528 MB.

  • Page 58: Installing The Central Processing Unit (Cpu)

    7. Press the lever down. The plate will slide forward. 8. Place the heatsink on top of the CPU and tighten it with the heatsink clip (shown in Fig. 4-3). 9. Attach the CPU fan to the CPU heatsink with the four screws. PPC-150 User's Manual...

  • Page 59: Figure 4-3: Installing The Cpu

    10. Connect the power cable of the CPU fan to the 2-pin connector (J12). 11. After changing the CPU, you must set jumpers, including those for the PCI bus clock (JP8), system/PCI clock (JP11), frequency ratio (JP14), and voltage (JP13). (See Section 5.2.) 12.

  • Page 60: Installing The Sdram Memory Module

    3. Insert the memory module into the socket at an angle of 90 degrees. 4. Push the two eject levers towards the vertical posts at each end of the socket until the module is upright. SDRAM Figure 4-4: Installing the SDRAM PPC-150 User's Manual...

  • Page 61: Installing The Floppy Disk Drive (Fdd)

    4.6 Installing the Floppy Disk Drive (FDD) Installation of a floppy disk drive is similar to that for a hard disk drive. The metal plate for holding the FDD is on the left side of the shielding case. The 26-pin yellow FPC cable is for connecting the FDD. Only 3.5" floppy disk drives (720 KB and 1.44 MB) can be attached to the metal plate.

  • Page 62: Installing The Cd-Rom Drive

    CD-ROM drive. The other end of the cable is connect- ed to CD-ROM connector J9 on the motherboard. 6. Rotate the retaining spring, to secure the CD-ROM connector (with converting PCB) in place. CD-ROM connector Retaining spring Compact CD-ROM drive Figure 4-6: Installing the CD-ROM drive PPC-150 User's Manual...

  • Page 63: Chapter 5 Jumper Settings And Connectors

    Jumper Settings and Connectors This chapter tells how to set up the panel PC hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedures. •...

  • Page 64: Jumpers And Connectors

    A pair of needle-nose pliers may be helpful when working with jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. PPC-150 User's Manual...

  • Page 65: Jumpers

    5.1.2 Jumpers The motherboard of the panel PC has a number of jumpers that allow you to configure your system to suit your applications. The table below lists the function of each of the board’s jumpers. Table 5-1: Jumpers and their functions Label Function COM3 RI pin setting (Reserved)

  • Page 66: Locating Jumpers

    JP5: COM2 JP12: CMOS RS-232/422/485 clear for setting external RTC JP2: COM4 RI pin setting (Reserved) JP4: COM2 JP3: COM2 JP1: COM3 RI RS-232/422/485 RS-232/422/485 pin setting setting setting (Reserved) Figure 5-1: Locating jumpers on the PPC-150 motherboard PPC-150 User's Manual...

  • Page 67: Connectors

    5.1.4 Connectors On-board connectors link the panel PC to external devices such as hard disk drives or floppy drives. The table below lists the function of each of the board’s connectors. Table 5-2: Panel PC connectors Label Function IR connector (Reserved) Flat panel display connector Flat panel display connector Internal COM4 connector...

  • Page 68: Locating Connectors

    J2: Flat panel display connector J16: Inverter power connector J9: CD-ROM connector P C M C I A J8: Floppy drive connector J15: Internal speaker J1: IR connector connector (Reserved) (Reserved) Figure 5-2: Locating connectors on the PPC-150 motherboard PPC-150 User's Manual...

  • Page 69: Cpu Installation And Upgrading

    5.2 CPU Installation and Upgrading ® You can upgrade to a higher power Pentium , AMD or Cyrix processor at any time. Simply remove the old CPU, install the new one, and set the jumpers for the new CPU type and speed. 5.2.1 System clock setting (JP11, JP8) JP11 and JP8 are used to set the CPU and PCI bus speeds respectively, to optimize the system's performance.

  • Page 70: Table 5-3: System/Pci Clock Setting (Jp11)

    Table 5-3: System/PCI clock setting (JP11) PCI clock CPU clock 25 MHz 50 MHz 30 MHz 60 MHz 33 MHz 66 MHz 28 MHz 55 MHz 38 MHz 75 MHz 42 MHz 83 MHz (Reserved) PPC-150 User's Manual...

  • Page 71: Cpu Core Voltage Setting (Jp13)

    Table 5-4: PCI bus clock setting (JP8) PCI clock * CPUCLK/2 32MHz * default setting 5.2.2 CPU core voltage setting (JP13) JP13 must be set to match the CPU type. The following chart shows the proper jumper settings for their respective V .

  • Page 72: Table 5-5: Cpu Voltage Setting (Jp13)

    CC (CORE) CC (CORE) CC (CORE) 1.30 V 1.35 V 1.40 V 1.45 V 1.50 V 1.55 V 1.60 V 1.65 V 1.70 V 1.75 V 1.80 V 1.85 V 1.90 V 1.95 V 2.00 V 2.05 V PPC-150 User's Manual...
  • Page 73 CC (CORE) CC (CORE) CC (CORE) CC (CORE) NONE 2.10 V 2.20 V 2.30 V 2.40 V 2.50 V 2.60 V 2.70 V 2.80 V 2.90 V 3.00 V 3.10 V 3.20 V 3.30 V 3.40 V 3.50 V Chapter 5 Jumper Settings and Connectors...

  • Page 74: Cpu Frequency Ratio Setting (Jp14)

    5.2.3 CPU frequency ratio setting (JP14) Table 5-6: CPU frequency ratio (for Intel) (JP14) P55C P54C 3.5x 1.5x 2.5x 2.5x PPC-150 User's Manual...

  • Page 75: Table 5-7: Cpu Frequency Ratio (For Amd K6, K6-2) (Jp14)

    Table 5-7: CPU frequency ratio (for AMD K6, K6-2) (JP14) 2.5x 3.5x 4.5x 5.5x Chapter 5 Jumper Settings and Connectors...

  • Page 76: Cmos Clear For External Rtc (Jp12)

    The panel PC supports Cyrix M1 CPU with its linear access mode on L2 cache. This mode is set through JP10. Table 5-9: Cyrix linear mode enable (JP10) * open = disable (normal operation) closed = Cyrix linear mode * default setting PPC-150 User's Manual...

  • Page 77: Reset System (Jp16)

    5.2.6 Reset system (JP16) Table 5-10: Reset system (JP16) * open = normal operation closed = reset system * default setting Chapter 5 Jumper Settings and Connectors...

  • Page 78: Com-Port Interface

    The IRQ and the address ranges for COM1, 2, 3, and 4 are fixed. However, if you wish to disable the port or change these parameters later you can do this in the system BIOS setup. The table overleaf shows the default settings for the panel PC’s serial ports. PPC-150 User's Manual...

  • Page 79: Com3/Com4/Ri Pin Setting (Jp2, Jp1) (Reserved)

    IRQ3: and COM2's address range is 3F8 ~ 3FF and its interrupt IRQ is IRQ4. COM3 and COM4 are another set. Their selectable function is the same as the COM1/COM2 set. Table 5-13: PPC-150 serial port default settings Port Address Range Interrupt...

  • Page 80: Vga Interface

    (JP6) * 5 V 3.3 V * default setting Configuration of the VGA interface is done exclusively via the software utility. You do not have to set any jumpers. Refer to Chapter 8 for software setup details. PPC-150 User's Manual...

  • Page 81: Panel Type Select (Jp9)

    5.4.2 Panel type select (JP9) Table 5-17: Panel type select (JP9) Maximum Display Maximum Display Resolution Type Resolution Type 1. 1024 x 768 DSTN color 2. 1280 x 1024 TFT color 3. 640 x 480 DSTN color 4. 800 x 600 DSTN color 5.
  • Page 82 (44 K BIOS only) 13.1024 x 768 TFT color 14. 1280 x 1024 DSTN color (44 K BIOS only) (44 K BIOS only) 15. 1024 x 600 TFT color 16. 1024 x 600 TFT color (48•K BIOS only) PPC-150 User's Manual...

  • Page 83: Watchdog Timer Configuration

    5.5 Watchdog Timer Configuration An on-board watchdog timer reduces the chance of disruptions which EMP (electromagnetic pulse) interference can cause. This is an invaluable protective device for standalone or unmanned applications. Setup involves one jumper and running the control software. (Refer to Appen- dix B.) 5.5.1 Watchdog activity selection (JP15) When the watchdog timer activates (i.e.
  • Page 84 PPC-150 User's Manual...

  • Page 85: Chapter 6 Pci Bus Ethernet Interface

    PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet Driver Installation for MS-DOS & WINDOWS 3.1 Installation for WINDOWS 95/98 Installation for WINDOWS NT • Further Information...

  • Page 86: Introduction

    6.2 Installation of Ethernet Driver Before installing the Ethernet driver, note the procedures below. You must know which operating system you are using in your PPC-150, and then refer to the corresponding installation flow chart. Then just follow the steps described in the flow chart. You will quickly and successfully complete the installation, even if you are not familiar with instructions for MS-DOS or WINDOWS.

  • Page 87: Installation For Ms-Dos & Windows 3.1

    6.2.1 Installation for MS-DOS & WINDOWS 3.1 If you want to set up your Ethernet connection under the MS-DOS or Windows 3.1 environment, you should first check your server operation system. For example, MS-NT, IBM-LAN server,Netware and so on. Then choose the correct driver to install in your panel PC. The installation procedures for various servers can be found in the directory path "LAN/TXT/*"...

  • Page 88: Installation For Windows 95

    S e le c t " A d ap ter", an d th e n c lic k "O K " b utto n . a. P re s s " H a ve D is k..." b u tto n. PPC-150 User's Manual...
  • Page 89 a. T yp e th e p ath " D:\LAN \W IN95". b . C lick " OK " b utto n. a .C ho os e the lig h te n ed " Realtek..." ite m . b . C lick " OK" b utto n. a.

  • Page 90: Installation For Windows 98

    . a. Select " Start", "Settings", "Control Panel", and " Netw ork" icon. b. C lick " Add" button. a. Select " Adapter", and then clic k "O K" button. a. Pres s "Have Disk..." button. PPC-150 User's Manual...
  • Page 91 a. T yp e th e path " D:\LAN \W IN 98". b . C lick "O K " b utto n. a .C hoos e the lig h te n ed " Realtek..." item . b . C lick " O K " b utto n. a.

  • Page 92: Installation For Windows Nt

    . P re s s the " O K " b u tto n. a . C h o os e the " R TL8139... " ite m . b . C lic k th e " O K " b u tto n. PPC-150 User's Manual...
  • Page 93 a . C hoo se s uitable R T L 8 13 9 D u ple x m od e for yo u r a pp licatio n. b . C lick " OK" b utto n. a . F inish ne tw o rk co nfigu ration , and the n click the "...

  • Page 94: Further Information

    6.3 Further Information Realtek web: www.realtek.com.tw Advantech web: www.advantech.com or www.advantech.com.tw PPC-150 User's Manual...

  • Page 95: Chapter 7 Pci Svga Setup

    PCI SVGA Setup • Introduction • Installation of SVGA Driver Installation for WINDOWS 3.1 Installation for WINDOWS 95/98 Installation for WINDOWS NT Installation for OS/2 • Further Information...

  • Page 96: Introduction

    1024 x 768. Display types CRT and panel displays can be used simultaneously. The PPC-150 can be set in one of three configurations: on a CRT, on a flat panel display, or on both simultaneously. The system is initially set to simultaneous display mode. The CD-ROM disc includes three *.COM files in the subdirectory...

  • Page 97: Installation Of Svga Driver

    Complete the following steps to install the SVGA driver. Follow the proce- dures in the flow chart that apply to the operating system that you you are using within your PPC-150. Important: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen.

  • Page 98: Installation For Windows 3.1

    7.2.1 Installation for Windows 3.1 PPC-150 User's Manual...
  • Page 99 a. Type the path of the operating system. a. When installation is completed, reboot the system. b. You will see the "ChipsCPL" icon in the control panel. ChipsCPL a. Double click "ChipsCPL". b. Adjust screen size, color and refresh rate to your preferences.

  • Page 100: Installation For Windows 95/98

    7.2.2 Installation for Windows 95/98 PPC-150 User's Manual...
  • Page 101 a. Select the highlighted item. b. Click the "OK" button. a. C & T 6 5 5 5 5 appears in the adapter label. b. Click the "Apply" button. a. Press "Yes" to reboot. a. R e p e a t S t e p 1 o n t h e p r e v i o u s p a g e of this manual.
  • Page 102 Press "OK" to exit. a. Press "Yes" to set the monitor type. a. Select "Standard", "Super VGA 800 x 600", or "XGA". b. Press the "OK" button. a. Choose "Restart" to reboot. E N D PPC-150 User's Manual...

  • Page 103: Installation For Windows Nt

    7.2.3 Installation for Windows NT a. Select "Start", "Settings", "Control Panel". b. Double click the "Display" icon. a. Choose the "Settings" label. b. Press the "Display Type" button. a. Press the "Change..." button. a. Click the "Have Disk..." button. Chapter 7 PCI SVGA Setup...
  • Page 104 C D - R O M d r i v e . b. Type "D:\VGA\NT40\" in the blank. c. Press the "OK" button. D:\VGA\NT40\ a. Select the highlighted item. b. Press the "OK" button. a. Press "Yes" to proceed. a. Press "OK" to reboot. PPC-150 User's Manual...
  • Page 105 a. Repeat Step 1 in this manual, to select the "Settings" label. b. Adjust resolution and color. c. Click "Test" to see the result. d. Click "OK" to save the setting. E N D Chapter 7 PCI SVGA Setup...
  • Page 106 Type "D: ", <Enter>. d. Type "setup D:C:", and press <Enter>. a. Press "OK" to shut down. a. Reboot again, by selecting "OS/2 System", "System Setup", "Display Driver Install". a. Enable "Primary Display". b. Click the "OK" button. PPC-150 User's Manual...
  • Page 107 a. Press "OK" one more time. a. Type "D:\" in the blank. b. Click the "Install..." button. a. Press "OK" to shut down and restart. a. Select "OS/2 System", "System Setup", "System". Chapter 7 PCI SVGA Setup...

  • Page 108: Further Information

    Change resolution and refresh rate. E N D 7.3 Further Information For further information about the PCI/SVGA installation in your PPC-150, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: C&T web site: www.chips.com Advantech web sites: www.advantech.com www.advantech.com.tw...

  • Page 109: Chapter 8 Audio

    Audio • Introduction • Installation of Audio Driver Installation for MS-DOS & WINDOWS 3.1 Installation for WINDOWS 95/98 Installation for WINDOWS NT Installation for OS/2...

  • Page 110: Introduction

    FM music synthesis (ESFM) by using the ES1869 audio controller from ESS Technology, Inc. The audio interface can record, compress, and play back voice, sound, and music with a built-in mixer control. The PPC-150 on board audio interface also supports the Plug and Play (PnP) standard and provides PnP configuration for audio, FM, and MPU-104 logical devices.

  • Page 111: Changing Settings In Dos

    8.2.2 Changing settings in DOS The audio controller settings can be changed in the DOS environment by using the DOS SETUP utility located in the UTILITY subdirectory of the CD-ROM. To change the settings, simply type DOSSET at the DOS prompt. Follow the instructions on screen to choose the new settings for the ES1869 audio controller.

  • Page 112: Controlling Volume In Dos

    Change CD volume Change synthesizer volume Change AuxB volume Change PC speaker volume Volume. Note: no xx means 0 The value range for volume is 0 ~ 15. (The PC speaker volume range is 0 ~ 7.) PPC-150 User's Manual...

  • Page 113: Installation For Windows 3.1

    8.2.4 Installation for WINDOWS 3.1 Note: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. a. Insert the disc into the C D - R O M d r i v e . b.

  • Page 114: Installation For Windows 95/98

    . C h oo se " So und , Video and gam e co ntrollers " ite m . b . C lick " N ext" butto n. a . P re ss "H ave D isk... " butto n. PPC-150 User's Manual...
  • Page 115 a. Ins ert " D rive rs an d U tilitie s " C D -R O M . b. T yp e th e p ath " D :\A udio\w in 95" c . C lic k "O K " butto n. a.

  • Page 116: Installation For Windows Nt

    . C lick the " A d d ..." butto n. a . C h oo se " U n listed or U p dated D river" ite m . b . C lick the " O K " b utto n . PPC-150 User's Manual...
  • Page 117 a . Ins ert "D rive rs a n d U tilities " C D -R O M . b . T yp e the pa th "D :\A udio\NT 40" c . C lic k "O K " bu tto n . a .
  • Page 118 PPC-150 User's Manual...

  • Page 119: Chapter 9 Award Bios Setup

    Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 120: Award Bios Setup

    9.1 Award BIOS Setup The PPC-150 comes with an Award BIOS chip that contains the ROM setup for your system. This chip serves as an interface between the processor and the rest of the mainboard's components. This chapter explains the informa- tion contained in the setup program and tells you how to modify the settings according to your system configuration.

  • Page 121: Standard Cmos Setup

    A setup program, built into the system BIOS, is stored in the CMOS RAM that allows the configuration settings to be changed. This program is execut- ed when the user changes the system configuration; when the user changes the system backup battery; or when the system detects a configuration error and asks the user to run the setup program.

  • Page 122: Hard Disk Configurations

    LBA mode, select "LBA" or "Large". However, if your hard disk supporting cylinder is more than 1024 MB and does not support the LBA function, you have to select "Large". If your hard disk supporting cylinder is below 1024 MB, select "Normal". PPC-150 User's Manual...

  • Page 123: Bios Features Setup

    9.4 BIOS Features Setup Figure 9-3: BIOS features setup screen Moving around the BIOS Features and Chipset Features setup programs works the same way as moving around the Standard CMOS setup program. (Refer to the next section for Chipset Features setup.) The BIOS Features setup program is shown above.
  • Page 124 The term typematic means that when a keyboard key is held down, the character is repeatedly entered until the key is released. When this item is enabled, you may change the typematic repeat rate. The options are: Disabled (Default), Enabled. PPC-150 User's Manual...
  • Page 125 T T T T T ypematic Rate (Chars/Sec) ypematic Rate (Chars/Sec) ypematic Rate (Chars/Sec) ypematic Rate (Chars/Sec) ypematic Rate (Chars/Sec) Sets the rate of a character repeat when the key is held down. The options are: 6 (Default), 8, 10, 12, 15, 20, 24, 30. T T T T T ypematic Delay (msec) ypematic Delay (msec) ypematic Delay (msec)

  • Page 126: Chipset Features Setup

    Video BIOS Cacheable Video BIOS Cacheable Video BIOS Cacheable Video BIOS Cacheable When enabled, allows the system to use the video BIOS codes from SRAMs, instead of the slower DRAMs or ROMs. The options are: Enabled (Default), Disabled. PPC-150 User's Manual...

  • Page 127: Power Management Setup

    Memory Hole at 15M-16M Memory Hole at 15M-16M Memory Hole at 15M-16M Memory Hole at 15M-16M Memory Hole at 15M-16M When enabled, the memory hole at the 15 MB address will be relocated to the 15 ~ 16 MB address range of the ISA cycle when the processor accesses the 15 ~ 16 MB address area.
  • Page 128 MODEM Use IRQ MODEM Use IRQ MODEM Use IRQ MODEM Use IRQ This feature allows you to select the IRQ# to meet your modem's IRQ#. The options are: 3 (Default), 4, 5, 7, 9, 10, 11, NA. PPC-150 User's Manual...
  • Page 129 Hot Key Power Of Hot Key Power Of Hot Key Power Of Hot Key Power Of Hot Key Power Of f f f f f This function is designated as "Disabled". HDD Of HDD Of HDD Of f After f After f After f After HDD Of...
  • Page 130 Dream Mode to execute the corresponding calling routine. The options are: Enabled, Disabled. The default values of IRQ3, 4, 5, 6, 7, 9, 10, 11, 12, 13, 14, 15 are all: Enabled. The default value of IRQ8 is: Disabled. PPC-150 User's Manual...

  • Page 131: Pnp/Pci Configuration Setup

    Note: Under certain operating systems such as Windoes NT 4.0 (Build 1381), the CD auto-insertion feature might have some effect on power management. It is recommended that the CD-ROM drive use the secondary channel, and that the following Power Manage- ment Setup features be set: HDD &...
  • Page 132 Since each IDE controller supports two separate hard drives, you can select the INT# for each. You will note that the primary has a lower interrupt than the secondary. Selecting PCI-AUTO allows the system to automatically determine how your IDE disk system is configured. PPC-150 User's Manual...

  • Page 133: Load Bios Defaults

    9.8 Load BIOS Defaults Figure 9-7: Load BIOS defaults screen The BIOS defaults screen contains the most appropriate values of the system parameters that allow minimum system performance. 9.9 Load Setup Defaults Selecting this field loads the factory defaults for BIOS and Chipset Features. The system will automatically detect these defaults.

  • Page 134: Integrated Peripherals

    These drives have a master/slave relationship which is determined by the cabling configuration used to attach them to the controller. Your system supports two IDE controllers - a primary and a secondary - so you have the ability to install up to four separate hard disks. PPC-150 User's Manual...
  • Page 135 PIO means Programmed Input/Output. Rather than having the BIOS issue a series of commands to effect a transfer to or from the disk drive, PIO allows the BIOS to tell the controller what it wants and then let the controller and the CPU perform the task by themselves.
  • Page 136 WDT Active When Power ON WDT Active When Power ON This is Advantech's patented watchdog function which can reboot the system should the computer hang in the BIOS checkup. The options are: 63 sec (Default), Disabled, 31 sec, 15 sec.

  • Page 137: Password Setting

    ECP Mode Use DMA ECP Mode Use DMA ECP Mode Use DMA ECP Mode Use DMA ECP Mode Use DMA You can choose different DMA modes for data transfer. The options are: 3 (Default), 1. PS/2 mouse function PS/2 mouse function PS/2 mouse function PS/2 mouse function PS/2 mouse function...

  • Page 138: Ide Hdd Auto Detection

    BIOS. After keying in all settings, press "Esc" to return to the main menu. For confirmation, enter the Standard CMOS Setup feature. PPC-150 User's Manual...

  • Page 139: Save And Exit Setup

    9.13 Save and Exit Setup Figure 9-10: Save and exit setup screen After you have made changes in the BIOS setup, press "Esc" to return to the main menu. Move the cursor to "Save and Exit Setup", or press "F10" and then press "Y", to change the CMOS Setup.
  • Page 140 PPC-150 User's Manual...

  • Page 141: Chapter 10 Touchscreen

    Touchscreen • Introduction • Installation of Driver for Resistive or SAW Touchscreen Installation for MS-DOS & WINDOWS 3.1 Installation for Windows 95/98 Installation for WINDOWS NT Installation for OS/2 • Installation of Driver for Capacitive Touchscreen Installation for Windows 95/98/NT...

  • Page 142: Introduction

    10.1 Introduction 10.1.1 General information The PPC-150's optional touchscreen incorporates advanced second-genera- tion 5-wire resistive, impact-resistant capacitive, or surface acoustic wave (SAW) technology. They allow 75%, 85%, and 91% light transmission respectively. The resistive and capacitive models have an antiglare surface, but the SAW model does not.

  • Page 143: Installation Of Driver For Resistive Or Saw

    The touchscreen driver for Windows 95 contains a native, 32-bit driver designed for Windows 95/98 and a 32-bit control panel program for the PPC-150 system. To facilitate the installation of the touchscreen driver, you should read the instructions in this chapter carefully before you attempt installation.

  • Page 144: Installation For Ms-Dos And Windows 3.1

    DOS environment. b. Press <Enter> to continue. a. Type the installing path of the ELO directory. a. Select "Dos.." or "Windows..". Windows 3.1 a. Follow the on-screen instructions. D O S Windows 3.1 a. Choose the "Serial" item. PPC-150 User's Manual...
  • Page 145 a. Select the "COM4" item. a. Press <Enter> to install. a. Set serial port IRQ to Windows 3.1 a. Type the Windows 3.1 path. D O S Windows 3.1 a. Add "nomouse.com" to "autoexec.bat" if there is no mouse driver installed.
  • Page 146 D O S W i n d o w s 3 . 1 a. Choose "Overwrite...". W i n d o w s 3 . 1 a. Type "go" to run calibration. b. Touch fix points to calibrate. PPC-150 User's Manual...
  • Page 147 a. Add -M6 behind monmouse in "autoexec.bat" to add "drag". E N D Chapter 10 Touchscreen...

  • Page 148: Installation For Windows 95/98

    . C lic k "Y es " b utton to res tart yo u r c o m p ute r. a. T ou ch ta rge ts to calib rate th e tou c hs cre e n co ntrolle r. PPC-150 User's Manual...

  • Page 149: Installation For Windows Nt

    10.2.3 Installation for WINDOWS NT a. Insert the "Drivers and Utilities" CD-ROM. b. Select "Start", "Run". c. Type the path. D:\Elotouch\monmouse\winnt\setup.exe eg. "D:\Elotouch\ monmouse\winnt\ setup.exe" a. Press the "Next" button. a. Set the directory path. a. Choose "Typical". Chapter 10 Touchscreen...
  • Page 150 Click "OK". a. Click "OK" but do not reboot. a. Click on the "My Computer" icon, and navigate to: "C":\winnt\system32\regedt32. a. From the left window, select: "Hkey_Local_Machine" "System", "CurrentControlSet", "Services", "Monmouse", "Parameters". PPC-150 User's Manual...
  • Page 151 a. Modify the items in right window: ComPort ControllerAddress ControllerLevel ControllerVector b. Click "OK" to save the settings. a. Exit and reboot. b. Select "Start", "Settings", "Control Panel". c. Double click "Elo touchscreen". a. Click "Calibrate". a. Test the calibration. E N D Chapter 10 Touchscreen...

  • Page 152: Installation For Os/2 (Monitormouse)

    MonitorMouse for OS/2. Configuration requires setting switches and/or installing jumpers that determine controller operating parameters. You will need these parameters when you install the MonitorMouse for OS/2 driver software. For controller installation instructions, refer to the IntelliTouch Product Manual or the AccuTouch Product Manual. PPC-150 User's Manual...
  • Page 153 STEP 2 - COPY THE SOFTWARE The following files are on the MonitorMouse for OS/2 disk: !READ.ME! Text file containing any additions or changes made after this manual was printed. MONMOU01.SYS Touchscreen driver for serial touchscreen controllers on PC bus systems. MONMOU02.SYS Touchscreen driver for serial touchscreen controllers on Micro Channel systems.
  • Page 154 140 for the AccuTouch E271-140 serial controller. <COM port> is: the number of the COM port where the serial output of the touchscreen controller is connected. <baud rate> matches the switch or jumper settings on the controller. PPC-150 User's Manual...
  • Page 155 Example MonitorMouse for OS/2 DEVICE command: Device=c:\elo\monmou01.sys 2210,1,9600 No Mouse If you do not wish to have a mouse connected, change the “stype=elomou$” flag to “type=elomou$” on the DEVICE=MOUSE.SYS command. Disabling the COM Drivers If your system COM ports are being used by the touchscreen and mouse, REM out the DEVICE=COM.SYS and DEVICE=VCOM.SYS commands (if present) in CONFIG.SYS.
  • Page 156 (-c flag). The calibration points are then set automatically each time the system is started. Recalibration should only be necessary after moving or resizing the video image, or after changing either the touchscreen, controller, or monitor. Close the touchscreen control panel. PPC-150 User's Manual...

  • Page 157: Installation Of Driver For Capacitive Touchscreen

    10.3 Installation of Driver for Capacitive Touch screen To facilitate installation of the touchscreen driver, you should read the instructions in this chapter carefully before you attempt installation. Note 1: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen.
  • Page 158 Type in: D:\ PPC120&150\ Microtouch\Tware54\ Setup.exe a. Follow the installation instructions, and click on "Next". a. If you accept the terms of the License Agreement, click on "Yes". a. Select the Serial [Default] controller. Click on "Next". PPC-150 User's Manual...

  • Page 159: Installation For Windows95/98/Nt

    a. Select the "Express Install..." item. b. Click on "Next". a. Select the "Yes, ..." item to reboot the system and finish the touchscreen driver installation. a. Click on "Calibrate" to calibrate the touchscreen. b. Touch the "target point" for a moment, until the next "Touch enable"...
  • Page 160 PPC-150 User's Manual...

  • Page 161: Appendix A Lcd Specifications And Selection Settings

    LCD Specifications and Selection Settings Appendix A LCD Specifications and Selection Settings...
  • Page 162 The color LCD display installed in the panel PC is high-quality and reliable. However, it may contain a few defective pixels which may not always illuminate. With current technology, it is impossible to completely eliminate defective pixels. Advantech is actively working to improve this technology. PPC-150 User's Manual...

  • Page 163: Appendix B Programming The Watchdog Timer

    Programming the Watchdog Timer The PPC-150 is equipped with a watch- dog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 164: Programming The Watchdog Timer

    I/O port 443 (hex) while simultaneously setting it. When you want to disable the watchdog timer, your program should read I/O port 443 (hex). The following example shows how you might program the watchdog timer in PPC-150 User's Manual...

  • Page 165: Appendix B Programming The Watchdog Timer

    BASIC: Watchdog timer example program OUT &H443, data REM Start and restart the watchdog GOSUB 1000 REM Your application task #1, OUT &H443, data REM Reset the timer GOSUB 2000 REM Your application task #2, OUT &H443, data REM Reset the timer X=INP (&H443) REM, Disable the watchdog timer 1000 Subroutine #1, your application task...
  • Page 166 PPC-150 User's Manual...

  • Page 167: Chapter C Full Disassembly Procedures

    Full Disassembly Procedures...
  • Page 168 If you want to completely disassemble the panel PC, follow the step-by-step procedures below. Users should be aware that Advantech Co., Ltd. takes no responsibility whatsoever for any problems or damage caused by the user disassembly of the panel PC. Make sure the power cord of the panel PC is unplugged before you start disassembly.

  • Page 169: Figure C-1: Steps 1 - 4

    Step 1 & Step 2 Step 4 Step 3 Figure C-1: Steps 1 - 4 Appendix C Full Disassembly Procedures...
  • Page 170 The EMI protection cover lies below the I/O bracket. You can now remove both the bracket and the cover from the I/O ports. 6. Detach the flat cables of the LCD inverter, touchscreen and LCD from the motherboard. You can remove the motherboard from the plastic housing. PPC-150 User’s Manual...

  • Page 171: Figure C-2: Steps 5 - 6

    I/O bracket Step 5 protection cover Motherboard Step 6 Figure C-2: Steps 5 - 6 Appendix C Full Disassembly Procedures...
  • Page 172 LCD or touchscreen. You just start disassembling the module from the step 8. Then you can easily remove the LCD and touchscreen by step 9 to step 12. PPC-150 User’s Manual...

  • Page 173: Figure C-3: Steps 7 - 12

    Power Step 7 supply Step 10 Plastic housing Step 11 Step 9 LCD holding plate Step 12 Touchscreen Step 8 Front panel Figure C-3: Steps 7 - 12 Appendix C Full Disassembly Procedures...
  • Page 174 PPC-150 User’s Manual...

  • Page 175: Chapter D Pin Assignments

    Pin Assignments • IR Connector (J1) (Reserved) • Flat Panel Display Connector (J2) • Flat Panel Display Connector (J3) • Internal COM4 Connector (J4) • Touchscreen Power Connector (J5) • Sandisk SSD Connector (J6) • EIDE Hard Disk Drive Connector (J7) •...

  • Page 176: Ir Connector (J1) (*Reserved)

    IR Connector (J1) (*Reserved) Table D-1: IR Connector (J1) Signal Mode_Select IR_IN IR_out PPC-150 User’s Manual...

  • Page 177: Flat Panel Display Connector (J2)

    Flat Panel Display Connector (J2) Table D-2: Flat Panel Display Connector (J2) Signal Signal +12 V +12 V SAFE SAFE ENAVEE SHFCLK M/DE ENABKL Appendix D Pin Assignments...

  • Page 178: Flat Panel Display Connector (J3)

    Flat Panel Display Connector (J3) Table D-3: Flat Panel Display (J3) Signal Signal SAFE +5 V Internal COM4 Connector (J4) Table D-4: Internal COM4 Connector (J4) Signal Signal PPC-150 User’s Manual...

  • Page 179: Touchscreen Power Connector (J5)

    Touchscreen Power Connector (J5) Table D-5: Touchscreen Power Connector (J5) Signal +5 V Appendix D Pin Assignments...

  • Page 180: Sandisk Ssd Connector (J6)

    DATA 15 SIGNAL GND HDD 0 IO WRITE IO READ HD READY HDACK 0 # IRQ14 ADDR 1 ADDR 0 ADDR 2 HDD SELECT 0 # HDD SELECT 1 # IDE ACTIVE 0 # # Low active PPC-150 User’s Manual...

  • Page 181: Eide Hard Disk Drive Connector (J7)

    EIDE Hard Disk Drive Connector (J7) 43 41 39..5 3 1 44 42 40..6 4 2 Table D-7: EIDE Hard Disk Drive Connector (J7) Pin Signal Signal IDE RESET # DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4...

  • Page 182: Floppy Drive Connector (J8)

    Table D-8: Floppy Drive Connector (J8) Signal Signal (+5 V) STEP INDEX (+5 V) WRITE DATA DRIVE SELECT (+5 V) WRITE DATA DISK CHANGE TRACK 0 WRITE PROTECT MOTOR ON READ DATA DIRECTION DENSITY SELECT SIDE 1 SELECT PPC-150 User’s Manual...

  • Page 183: Cpu Fan Power Connector (J10)

    CD-ROM Connector (J9) Table D-9: CD-ROM Connector (J9) Signal Signal Audio_L Audio_R IDE RESET # DATA8 DATA7 DATA9 DATA6 DATA10 DATA5 DATA11 DATA4 DATA12 DATA3 DATA13 DATA2 DATA14 DATA1 DATA15 DATA0 HDD 0 IO READ IO WRITE HD READY HD ACK 0 # IRQ 15 ADDR1 ADDR0...

  • Page 184: Pci/Isa Bus Expansion Connector (J11)

    C 1 5 G 1 7 H 1 7 D 1 6 C 1 6 G 1 8 H 1 8 D 1 7 C 1 7 G 1 9 H 1 9 D 1 8 C 1 8 PPC-150 User’s Manual...

  • Page 185: Table D-11: Pci/Isa Slot Pin Assignments (Pins A And B)

    Table D-11: PCI/ISA Slot Pin Assignments (Pins A and B) Signal Signal IOCHK IRQ9 -5 V DRQ2 -12 V +12 V IORDY SA19 SA18 SA17 SA16 DACK3 SA15 DRQ3 SA14 DACK1 SA13 DRQ1 SA12 SA11 SCLK SA10 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2...

  • Page 186: Table D-12: Pci/Isa Slot Pin Assignments (Pins C And D)

    Table D-12: PCI/ISA Slot Pin Assignments (Pins C and D) Signal Signal SBHE MEM16 LA23 IO16 LA22 IRQ10 LA21 IRQ11 LA20 IRQ12 LA19 IRQ15 LA18 IRQ14 LA17 DACKO MEMR DRQ0 MEMW DACK5 DRQ5 DACK6 SD10 DRQ6 SD11 DACK7 SD12 DRQ7 SD13 SD14 MASTER SD15 PPC-150 User’s Manual...

  • Page 187: Table D-13: Pci/Isa Slot Pin Assignments (Pins E And F)

    Table D-13: PCI/ISA Slot Pin Assignments (Pins E and F) Signal Signal INT 1 INT3 INT 2 INT4 PCLK2 GNT2 REQ2 GNT3 PCLK1 REQ3 AD31 AD30 AD29 AD28 AD27 AD26 AD25 AD24 CBE3 AD22 AD23 AD20 AD21 AD18 AD19 AD16 AD17 FRAME IRDY...

  • Page 188: Table D-14: Pci/Isa Slot Pin Assignments (Pins G And H)

    Table D-14: PCI/ISA Slot Pin Assignments (Pins G and H) Signal Signal SERR AD15 CBE1 AD14 AD12 AD13 AD10 AD11 CBEO PPC-150 User’s Manual...

  • Page 189: Fan Power Connector (J12)

    Fan Power Connector (J12) Table D-15: Fan Power Connector (J12) Signal +12 V AT Power Connector (J13) Table D-16: AT Power Connector (J13) Signal +5 V +12 V -12 V -5 V +5 V +5 V +5 V Appendix D Pin Assignments...

  • Page 190: Internal Speaker Connector (J15) (*Reserved)

    Internal Speaker Connector (J15) (*Reserved) Table D-18: Internal Speaker Connector (J15) Signal Speaker out_L Speaker out_R Inverter Power Connector (J16) Table D-19: Inverter Power Connector (J16) Signal +12 V ENABKL Brightness Adj. +5 V PPC-150 User’s Manual...

  • Page 191: Com2

    COM2 1 1 1 1 1 2 2 2 2 2 3 3 3 3 3 4 4 4 4 4 5 5 5 5 5 6 6 6 6 6 7 7 7 7 7 8 8 8 8 8 9 9 9 9 9 Table D-20: COM2 Signal RS-232...
  • Page 192 PPC-150 User’s Manual...

  • Page 193: Appendix E Mounting Instructions

    Mounting Instructions • Introduction • Panel Mounting • Desktop Stand Mounting • Swingarm Stand Mounting...

  • Page 194: Introduction

    E.1 Introduction The PPC-150 can be placed as is on a shelf or table, mounted into a panel, or mounted on a customized desktop stand. E.2 Panel Mounting E.2.1 Introduction Panel mounting can help system integrators conveniently integrate the panel PC into their system.

  • Page 195: Installation Procedure

    E.2.2 Installation Procedure To mount the PPC-150 into a panel: 1. Remove the front panel. There are ten holes located along the four sides of the panel PC. 2. Insert the screws from the front side into the holes and tighten them with the nuts provided.

  • Page 196: Cut-Out Area

    E.2.3 Cut-out area Refer to Figure E-3 below for the locations and dimensions of the cut-out area and mounting holes. Figure E-3: Dimensions of panel mounting holes PPC-150 User’s Manual...

  • Page 197: Desktop Stand Mounting

    E.3 Desktop Stand Mounting The PPC-150 has a customized stand suitable for desktops and other horizon- tal locations. A unique spring inside the stand enables the panel PC’s vertical tilt to be adjusted about 30 degrees. The stand is available from Advantech Follow these procedures to set up the stand: 1.

  • Page 198: Figure E-4: Desktop Stand Mounting

    Rear cover of panel PC Holding plate Top cover Main body Rear cover Base Figure E-4: Desktop stand mounting PPC-150 User’s Manual...

  • Page 199: Swingarm Stand Mounting

    E.4 Swingarm Stand Mounting The PPC-150 can be mounted on a unique swingarm. This versatile accesso- ry is easy to install and operate, and can be rotated through a wide range of angles. Its dimensions are shown in Figure E-5 below, and it is available from Advantech Co., Ltd.
  • Page 200 PPC-150 User’s Manual...

Table of Contents
