Copyright Notice This document is copyrighted, 1999, by Advantech Co. Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to alter the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech.
Page 4
FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.
Page 5
- Power cord (1.8 m) - USA type (other types are available on request) - Floppy disk with CD-ROM drive driver - "PPC-150 Drivers and Utilities" CD-ROM disc - Mounting kits and packet of screws - Heat sink with CPU fan (optional) (refer to Notes 1 and 2) If any of these items are missing or damaged, contact your distributor or sales representative immediately.
Page 6
Additional Information and Assistance 1. Visit the Advantech Web sites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
Page 7
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
Page 8
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Contents Chapter 1 General Information 1.1 Introduction ..............2 1.2 How to Use This Manual ..........4 1.3 Specifications..............6 General ..................6 Standard PC functions ..............6 PCI SVGA/flat panel interface ............7 Audio function ................. 7 PCI bus Ethernet interface ............. 8 Touchscreen (optional) ..............
Page 10
3.5 PS/2 Mouse and Keyboard .........27 3.6 PCI/ISA Bus Expansion ..........27 3.7 Parallel Port ..............29 3.8 Serial COM Ports ............29 3.9 VGA Port ..............30 3.10 Game Port ..............30 3.11 USB Ports ..............30 3.12 Audio Interface............31 3.13 Ethernet ..............31 3.14 Adjusting the LCD Contrast and Brightness ....31 3.15 Touchscreen (Optional) ..........32 Chapter 4 Hardware Installation and Upgrading 4.1 Overview of Hardware Installation and...
Page 12
8.2.1 Installation of MS-DOS ............90 8.2.2 Changing settings in DOS ........... 91 8.2.3 Controlling volume in DOS ..........92 8.2.4 Installation for WINDOWS 3.1 ..........93 8.2.5 Installation for WINDOWS 95/98 ......... 94 8.2.6 Installation for WINDOWS NT ..........96 Chapter 8 Award BIOS Setup 9.1 Award BIOS Setup ............100 9.2 CMOS Setup Utility ...........100...
Page 13
Appendix A LCD Specifications and Selection Settings Appendix B Programming the Watchdog Timer Programming the Watchdog Timer ........142 Appendix C Full Disassembly Procedures Appendix D in Assignments IR Connector (J1) (*Reserved) .......... 154 Flat Panel Display Connector (J2) ........155 Flat Panel Display Connector (J3) ........156 Internal COM4 Connector (J4) ..........156 Touchscreen Power Connector (J5) ........157 Sandisk SSD Connector (J6) ..........158...
Page 15
Table D-13: PCI/ISA Slot Pin Assignments (Pins E&F) ......165 Table D-14: PCI/ISA Slot Pin Assignments (Pins G&H) ......166 Table D-15: Fan Power Connector (J12) ..........167 Table D-16: AT Power Connector (J13) ..........167 Table D-17: Internal Speaker Connector (J15)........168 Table D-18: Inverter Power Connector (J16) .........
Page 16
Figures Figure 1-1:The panel PC in perspective............ 3 Figure 1-2: How to read the PPC-150 manual .......... 5 Figure 1-3: Dimensions of the PPC-150 ..........10 Figure 2-1: Front view of the panel PC ........... 12 Figure 2-2: Left side view of the panel PC ..........13 Figure 2-3: Rear view of the panel PC ............
General Information This chapter gives background information on the PPC-150 panel PC. • Introduction • How to Use This Manual • Specifications Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
PCMCIA expansion sockets, the PPC-150 is as compact and user-friendly as a notebook computer. Unlike notebook computers, the PPC-150 is more durable and versatile in all applications. The panel PC can be placed on a desktop to replace the traditional desktop computer. In addition, its "fit anywhere"...
Chapter 9 explains the Award BIOS setup. Chapter 10 explains how to configure and use the optional touchscreen. Appendix A details the LCD specifications used in the PPC-150. Appendix B explains how to program the watchdog timer. Appendix C includes various exploded diagrams of the PPC-150. These diagrams will help system integrators disassemble the panel PC.
Appendices A - E Systems Upgrades: Chapter 4-5 Commercial Users: Chapters 1-3, 6-9, 10 (optional) Figure 1-2: How to read the PPC-150 manual Chapter 1 General Information Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
• Serial ports: Four serial ports with three RS-232 ports (COM1, 3, and 4), one RS-232/422/485 port (COM2). All ports are compatible with 16C550 UARTs. • Universal serial bus (USB) port: Supports up to two USB ports • PCI/ISA bus expansion slot: Accepts either one ISA card or one PCI bus card •...
Note: The panel PC with the optionally installed touchscreen will share COM4. Once the touchscreen is installed, COM4 cannot be used for other purposes. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Chapter 2 System Setup Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 35
Note: Some distributors and system integrators may have already pre-installed system software prior to shipment of your panel PC. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 36
Chapter 2 System Setup Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 37
Note: The drivers and utilities used for the PPC-150 panel PCs are subject to change without notice. If in doubt, check Advantech's web site or contact our application engineers for the latest information regarding drivers and utlities. PPC-150 User's Manual...
NOTE! When you install a new CPU, be sure to adjust the board jumper settings. Improper settings may damage the CPU. (See Chapter 5 for jumper settings.) Chapter 4 Hardware Installation and Upgrading Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
DIMM module must line up with the small arrowhead printed on the motherboard next to the DIMM socket. The golden pins of the module must point down into the DIMM socket. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Label Function IR connector (Reserved) Flat panel display connector Flat panel display connector Internal COM4 connector Touchscreen power connector Sandisk SSD connector EIDE hard disk driver connector Floppy drive connector CD-ROM connector CPU fan power connector PCI/ISA bus expansion connector Fan power connector AT power connector Internal speaker connector (Reserved)
Page 69
1.50 V 1.55 V 1.60 V 1.65 V 1.70 V 1.75 V 1.80 V 1.85 V 1.90 V 1.95 V 2.00 V 2.05 V PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 70
CC (CORE) CC (CORE) CC (CORE) CC (CORE) NONE 2.10 V 2.20 V 2.30 V 2.40 V 2.50 V 2.60 V 2.70 V 2.80 V 2.90 V 3.00 V 3.10 V 3.20 V 3.30 V 3.40 V 3.50 V Chapter 5 Jumper Settings and Connectors Artisan Technology Group - Quality Instrumentation ...
Page 73
“3.0 V Battery On” before turning on the power supply. * normal operation Clear CMOS * open = disable (normal operation) closed = Cyrix linear mode PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 74
* open = normal operation closed = reset system Chapter 5 Jumper Settings and Connectors Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 76
+5 V output +12 V output * RI output +5 V output +12 V output * RI output Chapter 5 Jumper Settings and Connectors Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 77
* 5 V 3.3 V PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 78
Maximum Display Maximum Display Resolution Type Resolution Type 1. 1024 x 768 DSTN color 2. 1280 x 1024 TFT color 3. 640 x 480 DSTN color 4. 800 x 600 DSTN color 5. 640 x 480 SHARP TFT color 6. 640 x 480 18-bit TFT color 7.
Page 79
DSTN color (44 K BIOS only) (44 K BIOS only) 15. 1024 x 600 TFT color 16. 1024 x 600 TFT color (48•K BIOS only) PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 80
* System reset IRQ11 Chapter 5 Jumper Settings and Connectors Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 83
You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. Note 2: The CD-ROM drive is designated as "D" throughout this chapter. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Important: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. Note 1: The CD-ROM drive is designated as "D" throughout this chapter. Note 2: <Enter>...
Page 107
Note: The CD-ROM drive is designated as "D" throughout this chapter. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 110
Note: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. Chapter 8 Audio Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
This is because the BIOS is revised and updated from time to time. If in doubt, check Advantech's web site for the latest BIOS versions and related information. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ...
Note: It is strongly recommended that setup items in this section NOT be changed, because advanced knowledge is required to effect such changes. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Note: Under certain operating systems such as Windoes NT 4.0 (Build 1381), the CD auto-insertion feature might have some effect on power management. It is recommended that the CD-ROM drive use the secondary channel, and that the following Power Management Setup features be set: HDD &...
Note 1: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. Note 2: The CD-ROM drive is designated as "D" throughout this chapter. Chapter 10 Touchscreen Artisan Technology Group - Quality Instrumentation ...
Appendix A LCD Specifications and Selection Settings Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 157
However, it may contain a few defective pixels which may not always illuminate. With current technology, it is impossible to completely eliminate defective pixels. Advantech is actively working to improve this technology. PPC-150 User's Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 166
Appendix C Full Disassembly Procedures Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 167
You just start disassembling the module from the step 8. Then you can easily remove the LCD and touchscreen by step 9 to step 12. PPC-150 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 168
Appendix C Full Disassembly Procedures Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 172
Signal Signal +12 V +12 V SAFE SAFE ENAVEE SHFCLK M/DE ENABKL Appendix D Pin Assignments Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 173
Signal Signal SAFE +5 V Signal Signal PPC-150 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 174
Signal +5 V Appendix D Pin Assignments Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 176
Pin Signal Signal IDE RESET # DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 SIGNAL GND HDD 0 IO WRITE IO READ...
Page 177
WRITE DATA DRIVE SELECT (+5 V) WRITE DATA DISK CHANGE TRACK 0 WRITE PROTECT MOTOR ON READ DATA DIRECTION DENSITY SELECT SIDE 1 SELECT PPC-150 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 182
Signal Signal INT 1 INT3 INT 2 INT4 PCLK2 GNT2 REQ2 GNT3 PCLK1 REQ3 AD31 AD30 AD29 AD28 AD27 AD26 AD25 AD24 CBE3 AD22 AD23 AD20 AD21 AD18 AD19 AD16 AD17 FRAME IRDY CBE2 DEVSEL TRDY LOCK STOP PERR Appendix D Pin Assignments Artisan Technology Group - Quality Instrumentation ...
Page 183
Signal Signal SERR AD15 CBE1 AD14 AD12 AD13 AD10 AD11 CBEO PPC-150 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 184
Signal +12 V Signal +5 V +12 V -12 V -5 V +5 V +5 V +5 V Appendix D Pin Assignments Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 185
Signal Speaker out_L Speaker out_R Signal +12 V ENABKL Brightness Adj. +5 V PPC-150 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 186
6 7 8 9 Signal RS-232 RS-422 RS-485 DATA- DATA+ Appendix D Pin Assignments Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 189
Note: The panel thickness should not exceed 10 mm. PPC-150 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 190
Note: The panel thickness should not exceed 10 mm. Appendix E Mounting Instructions Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 191
The base of the stand has two plastic caps. If you pry off the caps, you can attach the stand to your desktop using the two screw holes. PPC-150 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 192
Appendix E Mounting Instructions Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 194
