P370/P470 Keyless RF Scanners Product Reference Guide

MCL-Designer

MCL-Designer was originally written for a scanner having a keypad and a display. It can
also be used for the P370/P470 Keyless RF Scanner, but the following guidelines should
be followed:
• When writing a new application, do not use the following commands:
• IK - Input Key
• IC - Input Cash
• ID - Input Date
• IH - Input Time.
• When using an existing MCL application, be aware that the above listed commands
as well as the display commands will be ignored by the scanner.
• If the scanner stops responding for any reason, return the scanner to its default
application by doing the following:
• Remove the scanner's battery.
• While holding the scanner's trigger button, place the scanner in the cradle.
• When a Lo-Hi beep is heard, release the trigger button.
• When the default application reloads, a Lo-Med-Hi beep is heard. Remove the
scanner from the cradle.
• Reinsert the battery
• Cycle power to the base.
After troubleshooting your MCL application, download it again to continue using it.
For a list of MCL-Designer related errors, see MCL-Code Errors on page C-4. For detailed
information about MCL-Designer refer to the MCL-Designer for Phaser Series User's
Guide, p/n 70-37689-xx.

123Scan

123Scan is an intuitive Windows based utility that allows you to customize your scanner
setup and generate Advanced Data Formatting (ADF) rules. An Advanced Data Formatting
rule gives you the ability to modify the bar code data before sending it to the host such as
appending a carriage return, or some other prefix/suffix value, to the bar code data. This
enhances capability between bar code data and your host software, allowing you to
program the scanner rather than modifying your host application. The cordless scanner can
be programmed via a cordless (RF) download or by scanning 123Scan generated
2-8
