Removing the Battery

1. Slide the release latch down using center indent and remove the cover.
It may be useful to use a coin for extra leverage:
Figure 1-8. Removing the Battery Compartment Cover
2. Slide the battery toward the bottom of the scanner and then, using the pull tab, pull
the bottom of the battery back and out of the scanner.

Inserting the Battery

1. Place the top portion of the battery (curved side up, contacts toward top) into the
scanner and then slide it up the handle.
2. Replace the battery compartment cover.
3. Slide the release latch up to secure the cover in place.
Battery
Compartment
Cover
Pull Tab
Figure 1-9. Pulling the Battery Out
Getting Started
Battery
Release
Latch
1-13
