Daikin FUQ71CVEB Installation Manual page 12

2.
1.
Projected part
Blocking material
1.
Blocking
material
Insert
Projected part
Upper decoration
panel
2.
Lift this part
slightly.
(Other side also.)
Lower
decoration
panel
Insert the
bent part.
(Until you
hear a cliking
sound.)
11
3.
Projected part
Fig. 12
Insert
Insulation
3.
Insert
Drain pan
Insulation
Upper decoration panel
1. 2.
Bent part of
blocking material
Blocking material
Insert so that the
sheet metal section
does not protrude
from the end of the
lower decoration panel.
Fig.13
Lower decoration panel
Lower decoration
panel
Drain pan
Clearance between
lower decoration
panel and drain pan
English
