8200 Series Mobile Computer

1.4 LCD

The mobile computer comes with a FSTN graphic LCD, 160 by 160 pixels resolutions,
which can be programmed to display text or graphics, such as specific font and company
logo, to meet varying application needs.
Options
English font
Chinese font
Other language fonts, company logo...
Note: The bottom line (ICON_ZONE) is reserved to display status icons, such as the
battery icon.

1.4.1 ADJUSTING THE BACKLIGHT

The backlight of screen and keypad helps ease reading under dim environments. It can
be turned on and adjusted decreasingly or increasingly by the following key
combinations. Keep pressing the key combination until the luminosity or contrast is
decreased or increased to a desired level. Alternatively, the luminosity and contrast can
be configured through programming or via System Menu. Refer to
3.2.3 Contrast.
Note: Using backlight while on battery power will substantially reduce battery power. We
suggest that you dim the backlight while working in a well-lit area or have it set to
be automatically turned off when not in use.
Key Combination
[ ]
[ ] + [Up]
[ ] + [Down]
[ ] + [Right]
[ ] + [Left]
Note: Hold down the first key, and keep pressing the second key for adjustment.
16
Reference Manual
Font Size (pixels)
Font size 6×8 (pixels)
Font size 8×16 (pixels)
Font size 12×12 (pixels)
Font size 16×16 (pixels)
Programmable
Action
Toggle ON/OFF the backlight
Turn ON the backlight and increase the luminosity of LCD
Turn ON the backlight and decrease the luminosity of LCD
Turn ON the backlight and increase the contrast of LCD
Turn ON the backlight and decrease the contrast of LCD
Characters by lines
26 characters by 18 lines
20 characters by 9 lines
13 characters by 12 lines
10 characters by 9 lines
3.2.2 Backlight and
