12 8000 Series Reference Manual
The functionality of each key combination is application-dependent. Below is a list of
the factory setting for a variety of key combinations.
Press and hold [FN], and then, press one of the following keys for a specific function:
Key Combination
[ENTER]
[UP]
[DOWN]

1.5.5 LCD

The mobile computer comes with a FSTN graphic LCD, 100 by 64 pixels resolutions,
which can be programmed to display text or graphics, such as specific font and company
logo, to meet varying application needs.
Options
English font
Chinese font
Other language fonts, company logo...
Note: Normally, the last column (ICON_ZONE) is reserved to display status icons, such
The backlight of screen and keypad helps ease reading under dim environments. Relevant
settings can be configured or adjusted by pressing the following key combinations:
Settings
Backlight ON/OFF
LCD Contrast
Action
Toggle ON/OFF the backlight of LCD and keypad at the same time
Adjust LCD to high contrast
Adjust LCD to low contrast
as the battery icon.
Font Size (pixels)
Font size 6×8 (pixels)
Font size 8×16 (pixels)
Font size 16×16 (pixels)
Programmable
Key Combination
[FN] + [Enter]
[FN] + [Up] or [FN] + [Down]
Characters by lines
16 characters by 8 lines
12 characters by 4 lines
7 characters by 4 lines
