USING 8200 MOBILE COMPUTER

This chapter explains the features and usage of the 8200 Series Mobile Computer. The
8200 family includes:
8200 Batch type
8230 Bluetooth Class 2 + 802.11b/g
8260 Bluetooth Class 2
IN THIS CHAPTER
1.1 Battery....................................................................... 9
1.2 Memory.................................................................... 11
1.3 Keypad..................................................................... 12
1.4 LCD ......................................................................... 16
1.5 Notifications.............................................................. 17
1.6 Data Capture ............................................................ 19
1.7 Charging & Communications........................................ 21
1.8 SD Card ................................................................... 26

1.1 BATTERY

1.1.1 MAIN BATTERY

The mobile computer is powered by a rechargeable 3.7 V/1200 mAh Li-ion battery pack.
When the mobile computer is turned on, it takes approx. 2.5 hours to charge it to full
from the power adaptor (using RS-232 cable or cradle) or approx. 4 hours from the USB
cable (at 500 mA).
For power-saving purpose, always turn off the backlight while working in a well-lit area.
When the backlight is on for extended periods of time, the main battery will become low
sooner than expected.
The smart battery icon on the LCD screen shows the status of power consumption. There
are two ways to monitor a low battery charge or discharged battery from the screen.
Examine the level of the 4-bar battery icon
Monitor voltage level (see 3.5 Power)
