Procom V50TYLA-B Installation Instructions And Homeowner's Manual page 10

Item #
1 Log set
2 Fan/Heater Assembly
3 Synchronization Motor-220Volt AC w/Terminal
4 Cord Power H05VV-F3GX1.0 w/Terminals
5 ON/OFF Switch
6 Heater Control (Thermostat)
7 Heater Control Knob
8 Flame Generator Assembly
9 Light Bulb Socket w/Wiring Assembly
10 Screen
11 Top Panel
12 Side Panel (Left and Right)
13 Lower Front Panel
14 Door
15 Brass Knob
16 Back Panel
17 Decorating Frame
18 Base
19 Leg
20 Upper (Mid) Louver
21 Upper Decorating Wire
22 Decorating Column
23 Switch Mount panel (not shown)
24 Pilot Light Bulb Socket w/ Wiring Assembly
V50TYLB-D
Part Description Part Number
VL050-01A
NFHTX186-R/VB17-000-R
FE23A307
NFHL008-R-A
VL067-01
VL053-02
NFHL012
PT/32G370/FE33A205-01
PE28A306-R
EB29600
VL028-01
VL029-01
EL012-06
EL013-01
224A
VL030-01-R
VL026-02
VL025-01K
VL023-01
VL015-01(VL014-01)
EL011-01
VL027-02
VL004-01F
VL075-01
9
