CONNECTING TO MONITORS*

Use the diagram below to connect to a Monitor or CRT Monitor properly.
DC 12V
CCTV Monitor
IR NO IR
Second Video Output
Monitor
300.0mm(11.8")
Power Connection: 12VDC Voltage.
All cameras are equipped with a second video output for on-site configuration.
14
