Flashing: (followed by a five-second pause) an error condition has occurred
Once = battery voltage is below Low Battery Cut-Out factory setting of 11.1 volts
(see Protection Circuitry section on Page 7 for a description of LBCO). The inverter
will automatically restart when battery voltage rises to 12.5 volts.
Twice = battery voltage is over 15.6 volts and inverter has shut down (see Page 7).
The inverter will automatically resume operating when battery voltage has dropped
below 15.6 volts.
Three = inverter is overheating and has shut off to protect itself. Reduce loads or
provide adequate ventilation. The inverter will automatically restart when cool.
Four = a charger fault has occurred. Return unit to an authorized Trace Service
Center for servicing.
Five or more: Not used with the Legend Series inverter/chargers.
3. BTS Port: An optional battery temperature sensor (BTS) can be plugged in at the RJ-11 four-
conductor connector. The BTS provides information that enables the three-stage standby
battery charger to " fine tune" the battery charge rates for better charging performance, greater
efficiency and longer life.
4. Stacking Port (not used). The Series II model is not a stackable unit.
5. Remote Control Port: The Legend Series II can be controlled up to 50 feet from the unit by
plugging in a remote control (RC6 or RC7). See the Options section for a complete description
of the RC6 and RC7 remote controls.
• The RC6 reports DC voltage, charging or inverter current, and turns the inverter on and off..
• The RC7 is a full function, programmable remote control with backlit LCD, battery capacity
and other meters.
6.
Battery Positive Terminal
7. Vehicle Chassis Ground Terminal
8. Battery Negative Terminal
9. AC Safety Ground
10. External Chassis (equipment) Ground
11. AC Terminal Block
