Introducing the TS Series Inverter
The Model TS Series microprocessor-controlled modified sinewave inverter converts DC
current into AC current. Rated at 400 to 800 watts continuous. Features include:
Power-saving Search mode
Easy installation
Battery voltage indicator
15-amp AC pass-thru circuit
User selectable low battery cutoff (LBCO)
Automatic transfer to inverter mode when AC supply is interrupted (with SB
option).
User selectable transfer sensitivity (with SB Option)
Optional dual 15-amp grounded AC outlet
Optional plug-in three-stage battery charger
Optional remote control
Copyright
Trace Engineering Co. Inc.
t h
5916 195 Street, NE
Arlington, WA 98223 USA
TS
TS
Tel (360) 435-8826
Fax (360)435-2229
www.traceengineering.com
Series
Part Number 3141
Effective Date: July 15, 1998
Page
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS and is the answer not in the manual?

Questions and answers

Related Manuals for Trace Engineering TS

Summary of Contents for Trace Engineering TS

  • Page 1 Series Introducing the TS Series Inverter The Model TS Series microprocessor-controlled modified sinewave inverter converts DC current into AC current. Rated at 400 to 800 watts continuous. Features include: Power-saving Search mode Easy installation Battery voltage indicator 15-amp AC pass-thru circuit...
  • Page 2 Product Materials Package Thank you for choosing Trace Engineering products to meet your alternative-energy power needs. We make every effort to ensure that your inverter/charger is properly packaged for shipping and includes all the materials requested. Every Trace inverter/charger is packaged with the following materials: Owner's Manual;...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS! This booklet contains important instructions for Model TS Series that should be followed during installation and maintenance of the unit. General Precautions Before using this device, read all instructions and cautionary markings on (a) the device, (b) the batteries and (C) all appropriate sections of this instruction booklet.

  • Page 4: Controls And Indicators

    AC Input AC Output Controls and Indicators The TS Series front panel features a power switch, four LEDs, and a fan on some models. The back panel configuration varies depending upon options. Front Panel Controls The TS Series front panel controls and indicators include a momentary push-button Power switch, a red error status indicator, a yellow charger status indicator, a green power light, and a white battery status indicator.

  • Page 5: Installation

    Inv On/Off Switch Operation The momentary push-button switch on the front panel controls the operating mode of the inverter: Search: Push the Inv On/Off switch once to enable Search mode. The power lamp will flash slowly in this mode. When in Search mode, the inverter emits a pulse testing the output circuits for loads.

  • Page 6: User Configuration Options

    For Deep Discharge, the two pins must be connected by the jumper. Transfer Sensitivity (SB Option Only) The TS inverter can be configured to begin inverting whenever grid voltage falls to 95 volts RMS (UPS mode) or to delay transfer until line voltage falls to 80 volts RMS (Gen mode).
  • Page 7 Float Volts Battery Type (SB Option Only) The TS Series can charge either liquid lead-acid (flooded) batteries or sealed, gel or absorbed glass batteries. The difference is in the charge voltages. The unit comes from the factory pre-configured for sealed batteries. To change to flooded batteries, remove the jumper from the pin pair labeled Sealed/Flooded.

  • Page 8: Sealed Gel Cell

    Sealed Gel Cell Sealed gel cell batteries do not use battery caps because the electrolyte is in the form of a gel. This allows the batteries to be mounted in any position without spilling. Other advantages are: no maintenance, long life (800 cycles claimed) , and low self-discharge. The disadvantage is high initial cost and the possibility of damage from overcharging.

  • Page 9: Standby Battery Charger

    Remove plug and install circuit breaker connect black wires to circuit breaker Options Field-installed options for the TS Series include either a three-stage standby battery charger (SB option), a battery temperature sensor (BTS option), and a remote control (RC8 option).
  • Page 10 C harging Bulk S tage Absorption S tage Float S tage S tarted B ulk V oltage Float V oltage 80-90% C apacity 100% capacity D C V oltage Two-Hour Absorption Period M ax C harge A m ps S etting D C &...

  • Page 11: Battery Temperature Sensor

    Cut a 1-7/8" diameter hole. At least 1½" of clearance is required behind the hole. Next drill the two holes needed to screw the installation to the wall. After routing the Trace remote cable, plug it into the six-conductor, RJ15 phone jack on the TS main PCB. Copyright Trace Engineering Co.

  • Page 12: Rear Panel Configuration

    Rear Panel Configuration The TS series rear panel configuration is determined by the model and options selected. Some models will have one or more of the features listed below: Duplex Outlet Option (D): a 120-volt, 15-amp outlet is provided on some models.
  • Page 13 Copyright Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3141 5916 195 Street, NE Fax (360)435-2229 Effective Date: July 15, 1998 Arlington, WA 98223 USA www.traceengineering.com Page...

  • Page 14: Troubleshooting

    Troubleshooting Symptoms Problem Remedy No AC power output AC routing wire disconnected reconnect wire See page 9 No warning LED’s Battery voltage at the inverter's Check voltage, fuses or terminals is too high or low breakers,cable connections No power output Load too small for Search defeat search mode, Search LED flashing...

  • Page 15: Limited 2 Year Warranty

    Warranty Limited 2 Year Warranty NOT FOR USE WITH LIFE SUPPORT EQUIPMENT Trace Engineering Company warrants its power products against defects in materials and workmanship for a period of two (2) years from the date of purchase and extends this warranty to all purchasers or owners of the product during the warranty period.
  • Page 16 Copyright Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3141 5916 195 Street, NE Fax (360)435-2229 Effective Date: July 15, 1998 Arlington, WA 98223 USA www.traceengineering.com Page...
