Digital Projection E-Vision Series User Manual page 17

DLP Projector—User's Manual
I L
TEM ABEL
1.
Power OFF
2.
DVI
3.
VGA
4.
DP
Up cursor /
5.
Keystone+
6.
ENTER
7.
Right cursor
Down cursor /
8.
Keystone-
9.
3D
10.
PICTURE MODE
11.
SOURCE
12.
CONTRAST
13.
BRIGHT
14.
SHARP
15.
COLOR
16.
FREEZE
17.
VOL +
18.
AUTO
19.
VOL -
20.
BLANK
21.
TINT
22.
MUTE
23.
STATUS
24.
ASPECT RATIO
25.
MENU
26.
Left cursor
27.
COMP
28.
VIDEO
29.
HDMI 1
30.
Power ON
31.
Status LED
32.
IR transmitter
Wired remote
33.
connector
D
ESCRIPTION
Turns the projector off
Displays the DVI source selection
Displays the VGA source selection
Displays the DisplayPort source selection
Navigates and changes settings in the OSD
Quick Menu – For Keystone
Enters and confirms settings in the OSD
Navigates and changes settings in the OSD
Navigates and changes settings in the OSD
Quick Menu – For Keystone
Activate 3D video
Changes the Display Mode setting
Alternate input source
Displays the contrast settings bar
Displays the brightness setting bar
Displays the sharpness setting bar
Displays the color setting bar
Freezes/unfreezes the on-screen picture
Adjusts volume
Auto adjustment for frequency, phase, and position
Adjusts volume
Makes the screen blank
Displays the tint setting bar
Mutes the built-in speaker
Opens the OSD Status menu (the menu only opens when an input
device is detected)
Displays the ASPECT RATIO selections
or closed
Opens the OSD
Navigates and changes settings in the OSD
Displays the Component source selection
Displays the VIDEO source selection
Displays the HDMI 1 source selection
Turns the projector on
Lights when the remote control is used
Transmits signals to projector
used
Wired remote function
— 8 —
S :
EE PAGE
13
22
22
22
22
22
13
