Installation & Setup

2.2 Hardware Installation

2.2.1 Connecting the Power Adapter
1. Connect the power adapter to the power outlet on the wall and to
the PWR power jack on the rear panel of the router.
2. The ACT LED should be blinking once every 2 seconds.
2.2.2 Connecting to the Ethernet
A. Connecting to PCs:
1. Attach the Ethernet cable (blue color cable) to any P1 ~ P6
port.
2. Connect the other end of the Ethernet cable to your PCs'
installed network interface card (NIC).
3. The LED indicators at both the Ethernet port and the NIC
should be ON.
4. Attach the Console cable to Console port.
5. Connect the other end of the Console cable to the
Management PC (p6~p23) you want to use to configure the
Vigor2000 Router.
Note:
If the Ethernet cable is not long enough to reach your PCs,
purchase a longer straight-through CAT. 5 UTP or STP
Ethernet cable.
B. Connecting to an External Ethernet Hub:
1. Attach the Ethernet cable (blue color cable) to the Uplink
port.
2. Connect the other end of the Ethernet cable to the external
2-4
