Ethernet hub or switch.
3. The LED indicators on both the Uplink port and the external
Ethernet hub or switch should be ON.
Note:
If the Ethernet cable is not long enough to reach the
external hub/switch, purchase a longer straight-
through 10Base-T Ethernet cable, or create a
handmade cable.
2.2.3 Connecting to an ISDN BRI Line
A. S/T-Interface Model
1. Locate the ISDN cable (black color cable).
2. Plug one of the RJ-45 connectors on the cable into the
ISDN port on the rear panel of the router.
3. Plug the other end of the cable into any of the NT-1 (or NT1
plus) S/T-interface ports.
B. U-Interface Model
1. Locate the ISDN cable (black color cable).
2. Plug one of the RJ-45 connectors on the cable into the
ISDN port on the rear panel of the router.
3. Plug the other end of the cable into the ISDN wall outlet.
2.2.4 Connecting to a DSL/Cable Modem
The router supports connection of a DSL modem via an Ethernet
interface only. Non-Ethernet interface DSL modems, such as USB
and ATMF-25, will not be supported.
1. Attach the Ethernet cable to the Ethernet port of the DSL/Cable
Installation & Setup
2-5
