2-8. Making graphic logo

2-8-1. About graphic logo

2-8-2. Making graphic logo procedure

Before following this procedure please allocate "Graphic logo" file (file 047) on the terminal.
QT-6000 Reference Manual
A graphic logo can be printed on internal receipt or UP-350 / UP-360 receipt. This graphic
logo is stored in the graphic logo file ( file 047 for UP-350 / UP-360), and printed at the
top of the receipt instead of a normal logo message.
This graphic logo data cannot be made by the terminal program, it can be made only by PC
and downloaded from PC.
Graphic logo size:
Printing sample:
**************************************
* QT-6000 TERMINAL
*
**************************************
*******COMMERCIAL MESSAGE LINE 1*******
*******COMMERCIAL MESSAGE LINE 2*******
*******COMMERCIAL MESSAGE LINE 3*******
*******COMMERCIAL MESSAGE LINE 4*******
1. Making a bit-map image file:
(432 × 104 or 432 × 208 pixels; 1-bit color for UP-350 / UP-360).
2. Convert this bit-map file to the internal file by executing "CV-10."
PC sends the converted data to the terminal via online automatically.
3. Select "Print Graphic" option in the message control of the general feature in the PGM
3 mode.
4. Turn off and on the terminal by the <DISP ON/OFF> button.
432 × 104 or 432 × 208 pixels
GRAPHIC LOGO AREA *
*
R-55
