Illumination/Charge lamp
mark
e
Read the IC card and make iC
transmissions.
Sub-display
Display the clock or FOMA terminal
status.
Camera ring illum./
Recording indicator
Infrared data port
Camera
Light
EXILIM Phone panel
Do not remove the sticker on the
back of the EXILIM Phone panel.
External connector terminal
Multi-terminal for charging,
connecting an earphone, etc.
Connect AC Adapter
(optional), DC Adapter
(optional), FOMA USB Cable
with Charge Function 02
(optional) or Stereo Earphone/
Microphone 01 (optional), etc.
HDMI micro plug (Type D)
Connect HDMI cable.
Charging terminal
6
GPS antenna
The antenna is built-in. Covering
the antenna part with your
hand may affect the quality.
FOMA antenna
The antenna is built-in. Covering
the antenna part with your
hand may affect the quality.
Speaker (monaural)
1Seg antenna/
FM transmitter antenna
Extend until
it stops
Change direction
without excessive
force
When storing the antenna, hold lower part and
push it until it stops.
n Screen lock key
Prevent unintentional
operation in Touch style.
microSD card slot
Volume up key
a
Raise the earpiece volume or
set Manner mode.
Volume down key
s
Lower the earpiece volume or
turn on the Light.
Shutter key
E
Strap hole
