Result code display example
When ATX0 is set
Regardless of the AT¥V command (p.45) setting, only CONNECT appears when the connection is completed.
Character indication example: ATD
Number indication example:
When ATX1 is set
ATX1, AT¥V0 are set (default)
Displayed in CONNECT <rate between the FOMA terminal and the PC> format when the connection is completed.
Character indication example: ATD
Number indication example:
*
¥
ATX1, AT V1 are set
The following format appears when the connection is completed:
CONNECT <rate between the FOMA terminal and the PC> PACKET <Connecting party's APN>/<Upstream (the
FOMA terminal Wireless base station) maximum rate>/<Downstream (the FOMA terminal
maximum rate>
The following sample indicates that a connection is made to mopera.ne.jp at maximum 5,440kbps for sending, and
maximum 7,232kbps for receiving.
Character indication example: ATD
Number indication example:
* If both ATX1 and AT¥V1 are set simultaneously, a dial-up connection may not be correctly made. The single setting
of AT¥V0 is recommended.
List of disconnection reasons
Packet communication
Value
26 Missing or incorrect APN.
27
30 Activation rejected by the network.
33 Requested service option not subscribed.
36 Disconnected successfully.
64K data communication
Value
1 The specified number does not exist.
16 Disconnected successfully.
17 Cannot communicate because the other party's line is busy.
18 Dialed, but no response within the specified time.
19 Cannot communicate because the other party is ringing.
21 The other party has rejected the communication.
63 The service or option of the network is not valid.
65 A transmission capacity not provided has been specified.
88 Sent to a terminal with different terminal attributes or received call.
99 1#
CONNECT
ATD 99 1#
1
99 1#
CONNECT 460800
ATD 99 1#
1 21
99 1#
CONNECT 460800 PACKET mopera.ne.jp/5440/7232
ATD 99 1#
1 21 5
51
Reason
Reason
Wireless base station)
