Setting up the access point (APN)
Default setting cid1 mopera.ne.jp
cid4 mpr.ex-pkt.net
Communication software to enter AT commands is required for the settings. This section describes
how to set it up using "Hyper terminal" that comes with Windows XP.
d Windows 7 and Windows Vista is not compatible with "Hyper terminal". For Windows 7 and Windows
Vista, set with compatible software. (Follow the instructions for the setting of the software.)
Access points <APN/cid>
d Normal telephone numbers are not used for access points for packet communication unlike 64K data
communication. Set up APN instead of a telephone number for connection.
d The APN setting is just like registering a Phonebook for packet communication from a PC. Assign
registration number (cid) 1 through 10 to register, which is used as a part of the access point number.
As the APN of mopera, "mopera.ne.jp" is assigned to cid1, APN of mopera U, "mopera.net" to cid2,
3, and APN of mopera U, " mpr.ex-pkt.net " to cid 4, respectively by default, assign the APN to cid5 to
*1
cid10.
d APN is administered by "cid (administration numbers 1 through 10)". Specifying "
number> " as the access point number enables the connection to the access point with the cid
number.
d Specifying "
99
" for the mopera U connection enables you to use mopera or mopera U easily.
d The APN setting registers the access point to the FOMA terminal just like registering other parties'
information (telephone number, etc.) on a mobile phone. The following are comparisons with the
Phonebook of the mobile phone:
Data to be registered
How to register Register using PC
Register using Mobile phone
How to use
d Registered cid will be connection numbers in the dialup connection settings.
d Contact your Internet service provider or network administrator for an access point (APN) other than
mopera U or mopera.
*1 Set up the APN setting for the access point (Internet service provider) on the FOMA terminal in advance instead of entering
APN in the Telephone Number column of "
*2 To connect to other Internet service providers, set the APN and assign it to cid5 to cid10.
<Example: Using the FOMA USB Cable with Charge Function 02 on Windows XP>
1
Connect the FOMA USB Cable with Charge Function 02 (optional) to the
FOMA terminal
2
Turn on the FOMA terminal, then connect the FOMA USB Cable with Charge
Function 02 connected to the FOMA terminal to the PC
cid2 mopera.net
cid5 to 10 not set
1 " as the access point number for the mopera connection or "
APN
cid
Available (DOCOMO Connection
Manager, etc.)
Unavailable (Cannot even check)
Specify cid to connect
cid3 mopera.net
APN setting
" (Dial-up Network) for connection.
25
99 <cid
99
*2
Phonebook of mobile phone
Phone number
Memory number of Phonebook
Other party's name
Available (Dedicated software
required)
Available
Look up Phonebook to call
Enter the telephone number directly
from the dial key on the FOMA
terminal to call.
3
